| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_230T04_9000000550_04418cztM0_level2.evt | modeM0/AS1G05_230T04_9000000550_04418cztM0_level2_quad_clean.evt |
| Size (bytes) | 500,057,280 | 89,369,280 |
| Size | 476.9 MB | 85.2 MB |
| Events in quadrant A | 2,853,936 | 577,583 |
| Events in quadrant B | 3,787,769 | 559,524 |
| Events in quadrant C | 2,890,460 | 575,131 |
| Events in quadrant D | 5,169,967 | 539,744 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3 | 0 |
| B | 0 | 3 | 0 |
| C | 0 | 3 | 0 |
| D | 0 | 3 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13353 | 2 |
| B | 0 | 15856 | 1 |
| C | 0 | 13428 | 1 |
| D | 0 | 19913 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6509 | 120 | 1.843601% |
| B | 6509 | 284 | 4.363189% |
| C | 6509 | 49 | 0.752804% |
| D | 6509 | 502 | 7.712398% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 6834 | 6510 | 0 | 0 | 0.00% | 0.00% |  |
| B | 6834 | 6510 | 115 | 115 | 1.68% | 1.77% |  |
| C | 6834 | 6510 | 1 | 1 | 0.01% | 0.02% |  |
| D | 6834 | 6510 | 479 | 479 | 7.01% | 7.36% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 11472 | 71.43 | 733 | 716 | 150.6 |
| A | 13 | 251 | 9970 | 61.46 | 733 | 716 | 150.6 |
| A | 12 | 194 | 7685 | 46.28 | 733 | 716 | 150.6 |
| B | 14 | 167 | 759052 | 5423.65 | 731 | 713 | 139.8 |
| B | 15 | 54 | 52315 | 369.06 | 731 | 713 | 139.8 |
| B | 0 | 231 | 42201 | 296.72 | 731 | 713 | 139.8 |
| C | 14 | 48 | 49634 | 297.78 | 710 | 711 | 164.3 |
| C | 9 | 16 | 31065 | 184.76 | 710 | 711 | 164.3 |
| C | 9 | 247 | 27262 | 161.61 | 710 | 711 | 164.3 |
| D | 13 | 114 | 2042774 | 12203.78 | 695 | 672 | 167.3 |
| D | 8 | 112 | 96991 | 575.61 | 695 | 672 | 167.3 |
| D | 2 | 37 | 92394 | 548.14 | 695 | 672 | 167.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
