| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1SLEW_01234_9000000559_04445cztM0_level2.evt | modeM0/AS1SLEW_01234_9000000559_04445cztM0_level2_quad_clean.evt |
| Size (bytes) | 32,587,200 | 1,912,320 |
| Size | 31.1 MB | 1.8 MB |
| Events in quadrant A | 247,834 | 2,632 |
| Events in quadrant B | 234,538 | 2,606 |
| Events in quadrant C | 226,491 | 2,570 |
| Events in quadrant D | 236,503 | 2,540 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 1137 | 0 |
| B | 0 | 1109 | 0 |
| C | 0 | 1113 | 0 |
| D | 0 | 1129 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 555 | 1 | 0.180180% |
| B | 555 | 0 | 0.000000% |
| C | 555 | 0 | 0.000000% |
| D | 555 | 0 | 0.000000% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 554 | 554 | 0 | 0 | 0.00% | 0.00% |  |
| B | 554 | 554 | 0 | 0 | 0.00% | 0.00% |  |
| C | 554 | 554 | 0 | 0 | 0.00% | 0.00% |  |
| D | 554 | 554 | 1 | 1 | 0.18% | 0.18% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 118 | 9374 | 635.01 | 61 | 59 | 14.7 |
| A | 8 | 15 | 1700 | 111.87 | 61 | 59 | 14.7 |
| A | 0 | 226 | 1421 | 92.85 | 61 | 59 | 14.7 |
| B | 12 | 111 | 910 | 61.85 | 60 | 59 | 13.8 |
| B | 11 | 111 | 729 | 48.69 | 60 | 59 | 13.8 |
| B | 8 | 61 | 575 | 37.5 | 60 | 59 | 13.8 |
| C | 12 | 4 | 1307 | 82.03 | 57 | 57 | 15.2 |
| C | 13 | 61 | 488 | 28.28 | 57 | 57 | 15.2 |
| C | 9 | 16 | 401 | 22.58 | 57 | 57 | 15.2 |
| D | 7 | 223 | 8159 | 499.8 | 58 | 56 | 16.2 |
| D | 7 | 39 | 3618 | 219.71 | 58 | 56 | 16.2 |
| D | 13 | 238 | 1951 | 116.89 | 58 | 56 | 16.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
