| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_253T03_9000000562_04477cztM0_level2.evt | modeM0/AS1G05_253T03_9000000562_04477cztM0_level2_quad_clean.evt |
| Size (bytes) | 501,528,960 | 81,872,640 |
| Size | 478.3 MB | 78.1 MB |
| Events in quadrant A | 3,720,965 | 491,833 |
| Events in quadrant B | 3,439,544 | 501,890 |
| Events in quadrant C | 3,475,611 | 504,271 |
| Events in quadrant D | 4,061,007 | 477,686 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 144 | 0 |
| B | 0 | 144 | 0 |
| C | 0 | 144 | 0 |
| D | 0 | 144 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 1 | 0 |
| B | 0 | 1 | 0 |
| C | 0 | 1 | 0 |
| D | 0 | 1 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16047 | 2 |
| B | 0 | 15110 | 3 |
| C | 0 | 15523 | 3 |
| D | 0 | 17031 | 6 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7242 | 355 | 4.901961% |
| B | 7241 | 237 | 3.273029% |
| C | 7241 | 171 | 2.361552% |
| D | 7240 | 304 | 4.198895% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7267 | 7243 | 93 | 93 | 1.28% | 1.28% |  |
| B | 7267 | 7243 | 1 | 1 | 0.01% | 0.01% |  |
| C | 7267 | 7243 | 44 | 44 | 0.61% | 0.61% |  |
| D | 7266 | 7242 | 89 | 89 | 1.22% | 1.23% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 50 | 195340 | 1089.13 | 858 | 837 | 178.6 |
| A | 0 | 118 | 188185 | 1049.06 | 858 | 837 | 178.6 |
| A | 0 | 226 | 26195 | 141.99 | 858 | 837 | 178.6 |
| B | 15 | 204 | 23314 | 131.51 | 871 | 851 | 170.8 |
| B | 4 | 48 | 17435 | 97.09 | 871 | 851 | 170.8 |
| B | 12 | 111 | 15008 | 82.88 | 871 | 851 | 170.8 |
| C | 9 | 54 | 152592 | 774.08 | 835 | 836 | 196.0 |
| C | 9 | 16 | 20190 | 98.72 | 835 | 836 | 196.0 |
| C | 9 | 247 | 16971 | 82.3 | 835 | 836 | 196.0 |
| D | 13 | 235 | 384182 | 1885.76 | 828 | 803 | 203.3 |
| D | 8 | 112 | 123460 | 603.32 | 828 | 803 | 203.3 |
| D | 5 | 51 | 107619 | 525.4 | 828 | 803 | 203.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
