| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_250T01_9000000568_04516cztM0_level2.evt | modeM0/AS1G05_250T01_9000000568_04516cztM0_level2_quad_clean.evt |
| Size (bytes) | 461,030,400 | 74,534,400 |
| Size | 439.7 MB | 71.1 MB |
| Events in quadrant A | 3,836,055 | 456,662 |
| Events in quadrant B | 3,313,787 | 461,697 |
| Events in quadrant C | 3,014,227 | 449,028 |
| Events in quadrant D | 3,353,759 | 433,179 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15829 | 3 |
| B | 0 | 14050 | 2 |
| C | 0 | 13516 | 2 |
| D | 0 | 14527 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 19 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6543 | 175 | 2.674614% |
| B | 6543 | 87 | 1.329665% |
| C | 6543 | 42 | 0.641907% |
| D | 6543 | 104 | 1.589485% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7808 | 6544 | 55 | 55 | 0.70% | 0.84% |  |
| B | 7808 | 6544 | 11 | 11 | 0.14% | 0.17% |  |
| C | 7808 | 6544 | 1 | 1 | 0.01% | 0.02% |  |
| D | 7808 | 6544 | 64 | 64 | 0.82% | 0.98% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 13 | 772574 | 4963.4 | 772 | 756 | 155.5 |
| A | 0 | 50 | 65269 | 414.87 | 772 | 756 | 155.5 |
| A | 15 | 234 | 13636 | 82.83 | 772 | 756 | 155.5 |
| B | 4 | 80 | 87764 | 587.66 | 787 | 770 | 148.0 |
| B | 8 | 3 | 78496 | 525.06 | 787 | 770 | 148.0 |
| B | 15 | 204 | 35753 | 236.32 | 787 | 770 | 148.0 |
| C | 9 | 247 | 63937 | 364.14 | 750 | 752 | 173.5 |
| C | 14 | 48 | 14968 | 81.93 | 750 | 752 | 173.5 |
| C | 12 | 4 | 7316 | 37.83 | 750 | 752 | 173.5 |
| D | 13 | 235 | 357640 | 2012.7 | 739 | 715 | 177.3 |
| D | 13 | 53 | 76140 | 425.32 | 739 | 715 | 177.3 |
| D | 2 | 136 | 42315 | 234.58 | 739 | 715 | 177.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
