| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_250T01_9000000568_04540cztM0_level2.evt | modeM0/AS1G05_250T01_9000000568_04540cztM0_level2_quad_clean.evt |
| Size (bytes) | 597,795,840 | 81,362,880 |
| Size | 570.1 MB | 77.6 MB |
| Events in quadrant A | 8,327,235 | 440,088 |
| Events in quadrant B | 3,226,830 | 528,658 |
| Events in quadrant C | 3,046,464 | 524,946 |
| Events in quadrant D | 3,060,210 | 513,503 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 29267 | 3 |
| B | 0 | 14196 | 2 |
| C | 0 | 13819 | 2 |
| D | 0 | 13996 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 16 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6531 | 2227 | 34.098913% |
| B | 6531 | 55 | 0.842137% |
| C | 6531 | 45 | 0.689022% |
| D | 6531 | 35 | 0.535906% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7586 | 6532 | 1399 | 1399 | 18.44% | 21.42% |  |
| B | 7586 | 6532 | 17 | 17 | 0.22% | 0.26% |  |
| C | 7586 | 6532 | 14 | 14 | 0.18% | 0.21% |  |
| D | 7586 | 6532 | 19 | 19 | 0.25% | 0.29% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 13 | 5821305 | 45865.46 | 621 | 606 | 126.9 |
| A | 8 | 15 | 86582 | 677.46 | 621 | 606 | 126.9 |
| A | 0 | 50 | 17916 | 136.39 | 621 | 606 | 126.9 |
| B | 15 | 204 | 92010 | 642.94 | 744 | 725 | 142.0 |
| B | 4 | 48 | 87124 | 608.53 | 744 | 725 | 142.0 |
| B | 4 | 80 | 60030 | 417.7 | 744 | 725 | 142.0 |
| C | 14 | 48 | 199584 | 1182.12 | 723 | 726 | 168.2 |
| C | 1 | 16 | 12466 | 69.79 | 723 | 726 | 168.2 |
| C | 1 | 3 | 6389 | 33.66 | 723 | 726 | 168.2 |
| D | 2 | 136 | 134860 | 786.27 | 716 | 697 | 170.6 |
| D | 13 | 235 | 65809 | 381.59 | 716 | 697 | 170.6 |
| D | 1 | 20 | 45618 | 263.26 | 716 | 697 | 170.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
