| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_214T01_9000000580_04641cztM0_level2.evt | modeM0/AS1G05_214T01_9000000580_04641cztM0_level2_quad_clean.evt |
| Size (bytes) | 566,717,760 | 65,188,800 |
| Size | 540.5 MB | 62.2 MB |
| Events in quadrant A | 3,570,711 | 363,892 |
| Events in quadrant B | 3,710,822 | 365,197 |
| Events in quadrant C | 3,527,802 | 369,406 |
| Events in quadrant D | 5,830,498 | 338,736 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 14 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15888 | 2 |
| B | 0 | 16015 | 2 |
| C | 0 | 15828 | 2 |
| D | 0 | 22685 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 158 | 0 |
| B | 0 | 158 | 0 |
| C | 0 | 158 | 0 |
| D | 0 | 158 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7711 | 116 | 1.504344% |
| B | 7711 | 108 | 1.400597% |
| C | 7711 | 92 | 1.193101% |
| D | 7711 | 597 | 7.742186% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9111 | 7713 | 1 | 1 | 0.01% | 0.01% |  |
| B | 9111 | 7713 | 3 | 3 | 0.03% | 0.04% |  |
| C | 9111 | 7713 | 6 | 6 | 0.07% | 0.08% |  |
| D | 9111 | 7713 | 430 | 430 | 4.72% | 5.58% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 7 | 16 | 20016 | 102.19 | 914 | 892 | 187.1 |
| A | 8 | 15 | 15986 | 80.65 | 914 | 892 | 187.1 |
| A | 13 | 251 | 12516 | 62.11 | 914 | 892 | 187.1 |
| B | 7 | 252 | 41414 | 224.82 | 923 | 898 | 180.2 |
| B | 4 | 80 | 27954 | 150.13 | 923 | 898 | 180.2 |
| B | 15 | 204 | 27276 | 146.37 | 923 | 898 | 180.2 |
| C | 7 | 191 | 25800 | 117.88 | 894 | 899 | 211.2 |
| C | 1 | 16 | 8428 | 35.64 | 894 | 899 | 211.2 |
| C | 13 | 61 | 7125 | 29.47 | 894 | 899 | 211.2 |
| D | 13 | 235 | 1313797 | 6217.41 | 863 | 837 | 211.2 |
| D | 8 | 112 | 648792 | 3068.33 | 863 | 837 | 211.2 |
| D | 2 | 136 | 158790 | 747.97 | 863 | 837 | 211.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
