| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_214T01_9000000580_04643cztM0_level2.evt | modeM0/AS1G05_214T01_9000000580_04643cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,574,501,760 | 219,015,360 |
| Size | 1.5 GB | 208.9 MB |
| Events in quadrant A | 9,424,524 | 1,360,732 |
| Events in quadrant B | 9,166,447 | 1,373,590 |
| Events in quadrant C | 8,848,109 | 1,389,868 |
| Events in quadrant D | 18,955,375 | 1,192,511 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 41385 | 4 |
| B | 0 | 39931 | 3 |
| C | 0 | 40079 | 3 |
| D | 0 | 69509 | 3 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 388 | 0 |
| B | 0 | 388 | 0 |
| C | 0 | 388 | 0 |
| D | 0 | 388 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 19095 | 578 | 3.026970% |
| B | 19095 | 356 | 1.864362% |
| C | 19095 | 214 | 1.120712% |
| D | 19095 | 3249 | 17.014925% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 20275 | 19098 | 52 | 52 | 0.26% | 0.27% |  |
| B | 20275 | 19098 | 28 | 28 | 0.14% | 0.15% |  |
| C | 20275 | 19098 | 3 | 3 | 0.01% | 0.02% |  |
| D | 20275 | 19098 | 2450 | 2450 | 12.08% | 12.83% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 111 | 947243 | 2132.37 | 2181 | 2135 | 443.2 |
| A | 13 | 251 | 23668 | 48.58 | 2181 | 2135 | 443.2 |
| A | 0 | 226 | 23477 | 48.15 | 2181 | 2135 | 443.2 |
| B | 10 | 16 | 200445 | 467.08 | 2216 | 2160 | 424.5 |
| B | 4 | 80 | 107638 | 248.46 | 2216 | 2160 | 424.5 |
| B | 15 | 204 | 93475 | 215.1 | 2216 | 2160 | 424.5 |
| C | 9 | 247 | 420246 | 829.95 | 2153 | 2161 | 503.7 |
| C | 13 | 61 | 17492 | 30.43 | 2153 | 2161 | 503.7 |
| C | 1 | 16 | 17055 | 29.57 | 2153 | 2161 | 503.7 |
| D | 13 | 235 | 7512670 | 15816.41 | 1969 | 1906 | 474.9 |
| D | 8 | 112 | 1324557 | 2785.28 | 1969 | 1906 | 474.9 |
| D | 2 | 63 | 919077 | 1931.41 | 1969 | 1906 | 474.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
