| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_251T02_9000000588_04674cztM0_level2.evt | modeM0/AS1G05_251T02_9000000588_04674cztM0_level2_quad_clean.evt |
| Size (bytes) | 264,879,360 | 42,661,440 |
| Size | 252.6 MB | 40.7 MB |
| Events in quadrant A | 1,223,313 | 292,070 |
| Events in quadrant B | 1,351,424 | 297,981 |
| Events in quadrant C | 1,214,618 | 300,450 |
| Events in quadrant D | 4,059,667 | 219,816 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 52 | 0 |
| B | 0 | 52 | 0 |
| C | 0 | 52 | 0 |
| D | 0 | 52 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5253 | 2 |
| B | 0 | 5613 | 1 |
| C | 0 | 5185 | 1 |
| D | 0 | 13808 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 2520 | 14 | 0.555556% |
| B | 2520 | 24 | 0.952381% |
| C | 2520 | 3 | 0.119048% |
| D | 2520 | 1003 | 39.801587% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 3835 | 2521 | 0 | 0 | 0.00% | 0.00% |  |
| B | 3835 | 2521 | 4 | 4 | 0.10% | 0.16% |  |
| C | 3835 | 2521 | 0 | 0 | 0.00% | 0.00% |  |
| D | 3835 | 2520 | 877 | 877 | 22.87% | 34.80% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 6153 | 88.92 | 312 | 305 | 65.8 |
| A | 7 | 16 | 5459 | 78.36 | 312 | 305 | 65.8 |
| A | 13 | 251 | 3712 | 51.8 | 312 | 305 | 65.8 |
| B | 15 | 204 | 47373 | 776.53 | 316 | 309 | 60.6 |
| B | 7 | 252 | 36548 | 597.92 | 316 | 309 | 60.6 |
| B | 4 | 80 | 11729 | 188.42 | 316 | 309 | 60.6 |
| C | 14 | 67 | 11822 | 159.82 | 306 | 307 | 72.1 |
| C | 12 | 4 | 2710 | 33.35 | 306 | 307 | 72.1 |
| C | 13 | 61 | 2537 | 30.95 | 306 | 307 | 72.1 |
| D | 8 | 112 | 2162604 | 35842.71 | 247 | 240 | 60.3 |
| D | 10 | 15 | 567122 | 9396.47 | 247 | 240 | 60.3 |
| D | 2 | 63 | 157909 | 2613.47 | 247 | 240 | 60.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
