| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_207T01_9000000596_04745cztM0_level2.evt | modeM0/AS1G05_207T01_9000000596_04745cztM0_level2_quad_clean.evt |
| Size (bytes) | 483,148,800 | 82,062,720 |
| Size | 460.8 MB | 78.3 MB |
| Events in quadrant A | 3,116,741 | 523,473 |
| Events in quadrant B | 3,070,276 | 534,115 |
| Events in quadrant C | 4,855,383 | 490,391 |
| Events in quadrant D | 3,159,144 | 494,409 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13691 | 3 |
| B | 0 | 13361 | 2 |
| C | 0 | 18815 | 2 |
| D | 0 | 13906 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 12 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6334 | 81 | 1.278813% |
| B | 6334 | 80 | 1.263025% |
| C | 6334 | 735 | 11.604042% |
| D | 6334 | 102 | 1.610357% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7469 | 6335 | 6 | 6 | 0.08% | 0.09% |  |
| B | 7469 | 6335 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7469 | 6335 | 558 | 558 | 7.47% | 8.81% |  |
| D | 7469 | 6335 | 23 | 23 | 0.31% | 0.36% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 7 | 16 | 113270 | 705.2 | 774 | 757 | 159.5 |
| A | 0 | 50 | 14480 | 86.01 | 774 | 757 | 159.5 |
| A | 13 | 14 | 12674 | 74.69 | 774 | 757 | 159.5 |
| B | 14 | 167 | 19708 | 125.86 | 782 | 762 | 150.5 |
| B | 12 | 111 | 14350 | 90.27 | 782 | 762 | 150.5 |
| B | 11 | 111 | 11374 | 70.5 | 782 | 762 | 150.5 |
| C | 14 | 48 | 2066744 | 12475.58 | 713 | 717 | 165.6 |
| C | 13 | 61 | 5609 | 29.54 | 713 | 717 | 165.6 |
| C | 7 | 247 | 3281 | 15.48 | 713 | 717 | 165.6 |
| D | 13 | 235 | 88441 | 483.91 | 752 | 731 | 181.3 |
| D | 1 | 31 | 62960 | 343.32 | 752 | 731 | 181.3 |
| D | 13 | 137 | 57358 | 312.42 | 752 | 731 | 181.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
