| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_212T01_9000000600_04765cztM0_level2.evt | modeM0/AS1G05_212T01_9000000600_04765cztM0_level2_quad_clean.evt |
| Size (bytes) | 556,778,880 | 93,386,880 |
| Size | 531.0 MB | 89.1 MB |
| Events in quadrant A | 3,155,343 | 594,469 |
| Events in quadrant B | 3,373,668 | 597,674 |
| Events in quadrant C | 3,999,619 | 586,852 |
| Events in quadrant D | 5,854,075 | 556,425 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14575 | 4 |
| B | 0 | 15030 | 3 |
| C | 0 | 16380 | 3 |
| D | 0 | 22431 | 3 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 16 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 142 | 0 |
| B | 0 | 142 | 0 |
| C | 0 | 142 | 0 |
| D | 0 | 142 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7078 | 57 | 0.805312% |
| B | 7078 | 56 | 0.791184% |
| C | 7078 | 84 | 1.186776% |
| D | 7078 | 515 | 7.276067% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7673 | 7080 | 11 | 11 | 0.14% | 0.16% |  |
| B | 7673 | 7080 | 1 | 1 | 0.01% | 0.01% |  |
| C | 7673 | 7080 | 13 | 13 | 0.17% | 0.18% |  |
| D | 7673 | 7080 | 407 | 407 | 5.30% | 5.75% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 61650 | 377.23 | 790 | 769 | 161.4 |
| A | 0 | 149 | 36771 | 223.08 | 790 | 769 | 161.4 |
| A | 0 | 226 | 11101 | 64.02 | 790 | 769 | 161.4 |
| B | 14 | 167 | 189322 | 1224.39 | 802 | 780 | 154.0 |
| B | 15 | 204 | 30369 | 192.15 | 802 | 780 | 154.0 |
| B | 15 | 54 | 25589 | 161.11 | 802 | 780 | 154.0 |
| C | 14 | 48 | 919660 | 5145.53 | 772 | 773 | 178.6 |
| C | 1 | 16 | 63809 | 352.99 | 772 | 773 | 178.6 |
| C | 13 | 61 | 6272 | 30.79 | 772 | 773 | 178.6 |
| D | 11 | 132 | 2312046 | 12789.27 | 752 | 727 | 180.7 |
| D | 2 | 136 | 546390 | 3019.33 | 752 | 727 | 180.7 |
| D | 2 | 234 | 52243 | 285.05 | 752 | 727 | 180.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
