| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_218T05_9000000602_04774cztM0_level2.evt | modeM0/AS1G05_218T05_9000000602_04774cztM0_level2_quad_clean.evt |
| Size (bytes) | 607,510,080 | 82,972,800 |
| Size | 579.4 MB | 79.1 MB |
| Events in quadrant A | 3,135,867 | 546,010 |
| Events in quadrant B | 3,519,154 | 534,161 |
| Events in quadrant C | 6,028,472 | 485,114 |
| Events in quadrant D | 5,286,872 | 505,038 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13712 | 2 |
| B | 0 | 14649 | 1 |
| C | 0 | 22177 | 1 |
| D | 0 | 20074 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6334 | 60 | 0.947269% |
| B | 6334 | 63 | 0.994632% |
| C | 6334 | 765 | 12.077676% |
| D | 6334 | 209 | 3.299653% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7519 | 6335 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7519 | 6335 | 25 | 25 | 0.33% | 0.39% |  |
| C | 7519 | 6335 | 629 | 629 | 8.37% | 9.93% |  |
| D | 7519 | 6335 | 173 | 173 | 2.30% | 2.73% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 185738 | 1220.05 | 755 | 738 | 151.6 |
| A | 0 | 50 | 9671 | 58.91 | 755 | 738 | 151.6 |
| A | 14 | 111 | 9669 | 58.9 | 755 | 738 | 151.6 |
| B | 14 | 167 | 326597 | 2301.34 | 754 | 738 | 141.6 |
| B | 4 | 80 | 157706 | 1108.57 | 754 | 738 | 141.6 |
| B | 15 | 204 | 62916 | 439.12 | 754 | 738 | 141.6 |
| C | 14 | 48 | 3189237 | 19789.68 | 695 | 697 | 161.1 |
| C | 1 | 16 | 120551 | 743.87 | 695 | 697 | 161.1 |
| C | 13 | 61 | 5647 | 30.72 | 695 | 697 | 161.1 |
| D | 11 | 132 | 1932851 | 11069.46 | 726 | 704 | 174.5 |
| D | 2 | 234 | 250208 | 1429.43 | 726 | 704 | 174.5 |
| D | 2 | 206 | 70239 | 398.37 | 726 | 704 | 174.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
