| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_142T01_9000000610_04818cztM0_level2.evt | modeM0/AS1G05_142T01_9000000610_04818cztM0_level2_quad_clean.evt |
| Size (bytes) | 328,740,480 | 59,849,280 |
| Size | 313.5 MB | 57.1 MB |
| Events in quadrant A | 2,257,031 | 375,444 |
| Events in quadrant B | 2,638,501 | 373,104 |
| Events in quadrant C | 2,150,509 | 377,513 |
| Events in quadrant D | 2,593,937 | 360,355 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 94 | 0 |
| B | 0 | 94 | 0 |
| C | 0 | 94 | 0 |
| D | 0 | 94 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9820 | 0 |
| B | 0 | 10917 | 0 |
| C | 0 | 9603 | 0 |
| D | 0 | 11024 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4636 | 118 | 2.545298% |
| B | 4636 | 115 | 2.480587% |
| C | 4636 | 57 | 1.229508% |
| D | 4636 | 135 | 2.911993% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 4636 | 4636 | 2 | 2 | 0.04% | 0.04% |  |
| B | 4635 | 4635 | 37 | 37 | 0.80% | 0.80% |  |
| C | 4636 | 4636 | 15 | 15 | 0.32% | 0.32% |  |
| D | 4635 | 4635 | 47 | 47 | 1.01% | 1.01% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 251 | 97263 | 867.17 | 543 | 531 | 111.5 |
| A | 15 | 249 | 40517 | 358.46 | 543 | 531 | 111.5 |
| A | 8 | 15 | 12022 | 103.01 | 543 | 531 | 111.5 |
| B | 4 | 80 | 464791 | 4375.18 | 547 | 535 | 106.1 |
| B | 15 | 204 | 12778 | 115.38 | 547 | 535 | 106.1 |
| B | 10 | 16 | 12710 | 114.74 | 547 | 535 | 106.1 |
| C | 9 | 247 | 62696 | 504.52 | 528 | 532 | 123.2 |
| C | 12 | 4 | 12765 | 99.28 | 528 | 532 | 123.2 |
| C | 8 | 208 | 11846 | 91.82 | 528 | 532 | 123.2 |
| D | 2 | 136 | 199746 | 1568.57 | 526 | 511 | 127.0 |
| D | 13 | 235 | 182810 | 1435.23 | 526 | 511 | 127.0 |
| D | 13 | 105 | 79730 | 623.69 | 526 | 511 | 127.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
