| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_253T02_9000000614_04843cztM0_level2.evt | modeM0/AS1G05_253T02_9000000614_04843cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,584,866,880 | 242,029,440 |
| Size | 1.5 GB | 230.8 MB |
| Events in quadrant A | 10,853,796 | 1,441,713 |
| Events in quadrant B | 11,767,259 | 1,437,953 |
| Events in quadrant C | 10,979,534 | 1,456,449 |
| Events in quadrant D | 12,814,633 | 1,382,934 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 25 | 0 |
| B | 0 | 25 | 0 |
| C | 0 | 25 | 0 |
| D | 0 | 25 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 478 | 6 |
| B | 0 | 478 | 2 |
| C | 0 | 478 | 0 |
| D | 0 | 478 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 49024 | 151 |
| B | 0 | 50942 | 188 |
| C | 0 | 49786 | 152 |
| D | 0 | 55153 | 243 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 23411 | 470 | 2.007603% |
| B | 23397 | 356 | 1.521563% |
| C | 23411 | 187 | 0.798770% |
| D | 23396 | 699 | 2.987690% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 26036 | 23482 | 45 | 45 | 0.17% | 0.19% |  |
| B | 26036 | 23479 | 69 | 69 | 0.27% | 0.29% |  |
| C | 26036 | 23477 | 1 | 1 | 0.00% | 0.00% |  |
| D | 26036 | 23475 | 368 | 368 | 1.41% | 1.57% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 251 | 217297 | 390.44 | 2674 | 2610 | 549.9 |
| A | 14 | 111 | 200003 | 358.99 | 2674 | 2610 | 549.9 |
| A | 0 | 50 | 119773 | 213.08 | 2674 | 2610 | 549.9 |
| B | 8 | 3 | 550159 | 1054.63 | 2707 | 2642 | 519.2 |
| B | 10 | 16 | 210890 | 401.13 | 2707 | 2642 | 519.2 |
| B | 4 | 80 | 205932 | 391.58 | 2707 | 2642 | 519.2 |
| C | 8 | 208 | 718477 | 1179.83 | 2606 | 2612 | 606.8 |
| C | 1 | 16 | 33654 | 51.16 | 2606 | 2612 | 606.8 |
| C | 8 | 128 | 30460 | 45.9 | 2606 | 2612 | 606.8 |
| D | 13 | 235 | 990383 | 1569.44 | 2574 | 2492 | 629.5 |
| D | 2 | 234 | 800957 | 1268.5 | 2574 | 2492 | 629.5 |
| D | 2 | 136 | 408622 | 645.21 | 2574 | 2492 | 629.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
