| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_157T01_9000000626_04950cztM0_level2.evt | modeM0/AS1G05_157T01_9000000626_04950cztM0_level2_quad_clean.evt |
| Size (bytes) | 510,330,240 | 101,649,600 |
| Size | 486.7 MB | 96.9 MB |
| Events in quadrant A | 4,061,844 | 658,883 |
| Events in quadrant B | 3,500,056 | 670,002 |
| Events in quadrant C | 3,104,793 | 664,557 |
| Events in quadrant D | 4,340,711 | 624,843 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 136 | 0 |
| B | 0 | 136 | 0 |
| C | 0 | 136 | 0 |
| D | 0 | 136 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16337 | 3 |
| B | 0 | 14657 | 2 |
| C | 0 | 13688 | 2 |
| D | 0 | 17397 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6590 | 344 | 5.220030% |
| B | 6590 | 119 | 1.805766% |
| C | 6590 | 68 | 1.031866% |
| D | 6591 | 357 | 5.416477% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7875 | 6590 | 222 | 222 | 2.82% | 3.37% |  |
| B | 7875 | 6590 | 20 | 20 | 0.25% | 0.30% |  |
| C | 7875 | 6590 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7876 | 6591 | 242 | 242 | 3.07% | 3.67% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 31 | 666868 | 4051.39 | 814 | 799 | 164.4 |
| A | 0 | 50 | 230968 | 1400.01 | 814 | 799 | 164.4 |
| A | 15 | 174 | 14841 | 85.41 | 814 | 799 | 164.4 |
| B | 15 | 204 | 109976 | 701.84 | 825 | 809 | 155.5 |
| B | 10 | 16 | 69604 | 442.29 | 825 | 809 | 155.5 |
| B | 4 | 48 | 41587 | 262.16 | 825 | 809 | 155.5 |
| C | 12 | 4 | 8005 | 40.01 | 791 | 794 | 180.2 |
| C | 13 | 61 | 6668 | 32.59 | 791 | 794 | 180.2 |
| C | 1 | 3 | 6174 | 29.85 | 791 | 794 | 180.2 |
| D | 2 | 33 | 467345 | 2393.81 | 790 | 766 | 194.9 |
| D | 13 | 235 | 423151 | 2167.07 | 790 | 766 | 194.9 |
| D | 2 | 136 | 113959 | 580.74 | 790 | 766 | 194.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
