| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_250T02_9000000638_05017cztM0_level2.evt | modeM0/AS1G05_250T02_9000000638_05017cztM0_level2_quad_clean.evt |
| Size (bytes) | 505,005,120 | 90,480,960 |
| Size | 481.6 MB | 86.3 MB |
| Events in quadrant A | 3,500,752 | 557,753 |
| Events in quadrant B | 3,421,815 | 565,236 |
| Events in quadrant C | 3,223,856 | 570,600 |
| Events in quadrant D | 4,653,940 | 540,294 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 18 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 148 | 0 |
| B | 0 | 148 | 0 |
| C | 0 | 148 | 0 |
| D | 0 | 148 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15209 | 3 |
| B | 0 | 15202 | 2 |
| C | 0 | 14976 | 2 |
| D | 0 | 19138 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7276 | 29 | 0.398571% |
| B | 7276 | 46 | 0.632216% |
| C | 7276 | 21 | 0.288620% |
| D | 7276 | 175 | 2.405168% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8991 | 7278 | 1 | 1 | 0.01% | 0.01% |  |
| B | 8991 | 7278 | 8 | 8 | 0.09% | 0.11% |  |
| C | 8991 | 7278 | 0 | 0 | 0.00% | 0.00% |  |
| D | 8991 | 7278 | 120 | 120 | 1.33% | 1.65% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 251 | 351985 | 2112.97 | 817 | 799 | 166.2 |
| A | 12 | 194 | 8176 | 44.38 | 817 | 799 | 166.2 |
| A | 0 | 226 | 8127 | 44.09 | 817 | 799 | 166.2 |
| B | 4 | 80 | 102022 | 630.14 | 832 | 812 | 160.6 |
| B | 15 | 204 | 47030 | 287.76 | 832 | 812 | 160.6 |
| B | 8 | 3 | 31379 | 190.31 | 832 | 812 | 160.6 |
| C | 1 | 16 | 60468 | 318.63 | 803 | 807 | 187.2 |
| C | 12 | 4 | 24961 | 129.0 | 803 | 807 | 187.2 |
| C | 13 | 61 | 6580 | 30.83 | 803 | 807 | 187.2 |
| D | 12 | 227 | 504176 | 2615.73 | 785 | 760 | 192.5 |
| D | 2 | 136 | 285351 | 1478.72 | 785 | 760 | 192.5 |
| D | 13 | 235 | 238470 | 1235.13 | 785 | 760 | 192.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
