| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_218T04_9000000640_05050cztM0_level2.evt | modeM0/AS1G05_218T04_9000000640_05050cztM0_level2_quad_clean.evt |
| Size (bytes) | 490,564,800 | 80,026,560 |
| Size | 467.8 MB | 76.3 MB |
| Events in quadrant A | 3,181,845 | 504,866 |
| Events in quadrant B | 3,239,029 | 498,021 |
| Events in quadrant C | 3,964,531 | 486,014 |
| Events in quadrant D | 4,024,926 | 475,612 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 16 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13622 | 3 |
| B | 0 | 13688 | 2 |
| C | 0 | 16180 | 2 |
| D | 0 | 16226 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6578 | 80 | 1.216175% |
| B | 6578 | 82 | 1.246580% |
| C | 6578 | 68 | 1.033749% |
| D | 6578 | 204 | 3.101247% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7803 | 6579 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7803 | 6579 | 1 | 1 | 0.01% | 0.02% |  |
| C | 7803 | 6579 | 5 | 5 | 0.06% | 0.08% |  |
| D | 7803 | 6579 | 105 | 105 | 1.35% | 1.60% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 50 | 20748 | 120.33 | 818 | 800 | 165.8 |
| A | 0 | 226 | 8165 | 44.43 | 818 | 800 | 165.8 |
| A | 12 | 194 | 8063 | 43.81 | 818 | 800 | 165.8 |
| B | 0 | 219 | 42689 | 267.59 | 813 | 795 | 156.6 |
| B | 15 | 204 | 28329 | 175.87 | 813 | 795 | 156.6 |
| B | 12 | 111 | 14032 | 84.55 | 813 | 795 | 156.6 |
| C | 1 | 16 | 910632 | 5083.62 | 775 | 781 | 179.0 |
| C | 14 | 67 | 24466 | 132.34 | 775 | 781 | 179.0 |
| C | 13 | 61 | 6517 | 32.05 | 775 | 781 | 179.0 |
| D | 12 | 233 | 355907 | 1868.53 | 782 | 759 | 190.1 |
| D | 13 | 235 | 201593 | 1056.64 | 782 | 759 | 190.1 |
| D | 1 | 7 | 177762 | 931.26 | 782 | 759 | 190.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
