| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_214T01_9000000652_05155cztM0_level2.evt | modeM0/AS1G05_214T01_9000000652_05155cztM0_level2_quad_clean.evt |
| Size (bytes) | 502,943,040 | 79,488,000 |
| Size | 479.6 MB | 75.8 MB |
| Events in quadrant A | 3,516,622 | 475,619 |
| Events in quadrant B | 3,776,280 | 481,424 |
| Events in quadrant C | 3,525,213 | 486,398 |
| Events in quadrant D | 3,919,945 | 457,799 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 148 | 0 |
| B | 0 | 148 | 0 |
| C | 0 | 148 | 0 |
| D | 0 | 148 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 20 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15236 | 3 |
| B | 0 | 15758 | 2 |
| C | 0 | 15238 | 2 |
| D | 0 | 16580 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7267 | 227 | 3.123710% |
| B | 7267 | 259 | 3.564057% |
| C | 7267 | 161 | 2.215495% |
| D | 7267 | 229 | 3.151232% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9232 | 7268 | 0 | 0 | 0.00% | 0.00% |  |
| B | 9232 | 7268 | 11 | 11 | 0.12% | 0.15% |  |
| C | 9232 | 7269 | 0 | 0 | 0.00% | 0.00% |  |
| D | 9232 | 7269 | 53 | 53 | 0.57% | 0.73% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 50 | 24252 | 124.66 | 906 | 884 | 187.5 |
| A | 12 | 194 | 8909 | 42.81 | 906 | 884 | 187.5 |
| A | 0 | 226 | 8814 | 42.3 | 906 | 884 | 187.5 |
| B | 15 | 204 | 46337 | 252.78 | 914 | 891 | 179.8 |
| B | 4 | 80 | 44771 | 244.07 | 914 | 891 | 179.8 |
| B | 5 | 175 | 36494 | 198.03 | 914 | 891 | 179.8 |
| C | 1 | 16 | 62919 | 300.85 | 886 | 891 | 206.2 |
| C | 13 | 61 | 7262 | 30.9 | 886 | 891 | 206.2 |
| C | 14 | 67 | 5065 | 20.25 | 886 | 891 | 206.2 |
| D | 1 | 239 | 333731 | 1525.9 | 883 | 857 | 218.1 |
| D | 10 | 15 | 69474 | 314.54 | 883 | 857 | 218.1 |
| D | 13 | 53 | 54451 | 245.68 | 883 | 857 | 218.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
