| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_104T01_9000000656_05194cztM0_level2.evt | modeM0/AS1G05_104T01_9000000656_05194cztM0_level2_quad_clean.evt |
| Size (bytes) | 426,718,080 | 75,366,720 |
| Size | 407.0 MB | 71.9 MB |
| Events in quadrant A | 2,965,028 | 463,372 |
| Events in quadrant B | 3,046,950 | 469,659 |
| Events in quadrant C | 2,911,521 | 467,178 |
| Events in quadrant D | 3,567,618 | 438,477 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 21 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13141 | 3 |
| B | 0 | 13230 | 2 |
| C | 0 | 12953 | 2 |
| D | 0 | 15008 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6349 | 46 | 0.724524% |
| B | 6349 | 48 | 0.756025% |
| C | 6349 | 23 | 0.362262% |
| D | 6349 | 201 | 3.165853% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7544 | 6350 | 3 | 3 | 0.04% | 0.05% |  |
| B | 7544 | 6350 | 4 | 4 | 0.05% | 0.06% |  |
| C | 7544 | 6350 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7544 | 6350 | 125 | 125 | 1.66% | 1.97% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 50 | 46144 | 296.96 | 753 | 740 | 152.9 |
| A | 4 | 2 | 13193 | 81.45 | 753 | 740 | 152.9 |
| A | 12 | 194 | 7567 | 44.65 | 753 | 740 | 152.9 |
| B | 4 | 48 | 35636 | 242.83 | 765 | 749 | 143.7 |
| B | 0 | 219 | 20931 | 140.48 | 765 | 749 | 143.7 |
| B | 15 | 204 | 13326 | 87.54 | 765 | 749 | 143.7 |
| C | 1 | 16 | 17187 | 97.84 | 741 | 745 | 168.0 |
| C | 13 | 61 | 5940 | 30.91 | 741 | 745 | 168.0 |
| C | 14 | 67 | 2999 | 13.41 | 741 | 745 | 168.0 |
| D | 2 | 63 | 336881 | 1931.1 | 724 | 704 | 174.1 |
| D | 7 | 237 | 165390 | 946.0 | 724 | 704 | 174.1 |
| D | 2 | 33 | 95388 | 543.89 | 724 | 704 | 174.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
