| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_104T01_9000000656_05199cztM0_level2.evt | modeM0/AS1G05_104T01_9000000656_05199cztM0_level2_quad_clean.evt |
| Size (bytes) | 496,408,320 | 104,492,160 |
| Size | 473.4 MB | 99.7 MB |
| Events in quadrant A | 3,620,616 | 659,166 |
| Events in quadrant B | 3,513,422 | 667,452 |
| Events in quadrant C | 3,402,034 | 675,058 |
| Events in quadrant D | 3,989,354 | 642,342 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5 | 0 |
| B | 0 | 5 | 0 |
| C | 0 | 5 | 0 |
| D | 0 | 5 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 154 | 0 |
| B | 0 | 154 | 0 |
| C | 0 | 154 | 0 |
| D | 0 | 154 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15962 | 3 |
| B | 0 | 15515 | 2 |
| C | 0 | 15404 | 2 |
| D | 0 | 17248 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7470 | 176 | 2.356091% |
| B | 7470 | 116 | 1.552878% |
| C | 7470 | 69 | 0.923695% |
| D | 7471 | 219 | 2.931334% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8015 | 7471 | 26 | 26 | 0.32% | 0.35% |  |
| B | 8015 | 7471 | 1 | 1 | 0.01% | 0.01% |  |
| C | 8015 | 7471 | 0 | 0 | 0.00% | 0.00% |  |
| D | 8016 | 7472 | 91 | 91 | 1.14% | 1.22% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 50 | 164426 | 921.08 | 863 | 842 | 177.6 |
| A | 4 | 2 | 137562 | 769.82 | 863 | 842 | 177.6 |
| A | 12 | 194 | 8657 | 44.0 | 863 | 842 | 177.6 |
| B | 15 | 204 | 90580 | 543.14 | 868 | 847 | 165.2 |
| B | 15 | 54 | 29253 | 171.94 | 868 | 847 | 165.2 |
| B | 12 | 111 | 14547 | 82.92 | 868 | 847 | 165.2 |
| C | 1 | 16 | 64963 | 329.71 | 846 | 847 | 194.5 |
| C | 12 | 4 | 18617 | 91.38 | 846 | 847 | 194.5 |
| C | 14 | 67 | 12704 | 60.97 | 846 | 847 | 194.5 |
| D | 2 | 136 | 311926 | 1509.71 | 843 | 815 | 206.1 |
| D | 2 | 33 | 281450 | 1361.82 | 843 | 815 | 206.1 |
| D | 2 | 63 | 102541 | 493.64 | 843 | 815 | 206.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
