| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C01_015T01_9000000668_05238cztM0_level2.evt | modeM0/AS1C01_015T01_9000000668_05238cztM0_level2_quad_clean.evt |
| Size (bytes) | 526,348,800 | 73,762,560 |
| Size | 502.0 MB | 70.3 MB |
| Events in quadrant A | 2,936,751 | 466,316 |
| Events in quadrant B | 3,018,991 | 473,410 |
| Events in quadrant C | 2,974,784 | 461,380 |
| Events in quadrant D | 6,584,561 | 394,885 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 20 | 0 |
| B | 0 | 20 | 0 |
| C | 0 | 20 | 0 |
| D | 0 | 21 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12895 | 3 |
| B | 0 | 12995 | 2 |
| C | 0 | 13016 | 2 |
| D | 0 | 23874 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6262 | 52 | 0.830406% |
| B | 6262 | 44 | 0.702651% |
| C | 6262 | 41 | 0.654743% |
| D | 6262 | 1247 | 19.913766% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7487 | 6263 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7487 | 6263 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7487 | 6263 | 1 | 1 | 0.01% | 0.02% |  |
| D | 7487 | 6263 | 979 | 979 | 13.08% | 15.63% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 226 | 7510 | 43.15 | 763 | 746 | 156.8 |
| A | 12 | 194 | 7373 | 42.28 | 763 | 746 | 156.8 |
| A | 13 | 251 | 2645 | 12.11 | 763 | 746 | 156.8 |
| B | 15 | 204 | 27138 | 178.81 | 773 | 756 | 147.5 |
| B | 12 | 111 | 14354 | 92.16 | 773 | 756 | 147.5 |
| B | 11 | 111 | 10875 | 68.58 | 773 | 756 | 147.5 |
| C | 1 | 16 | 78066 | 454.21 | 739 | 745 | 170.2 |
| C | 12 | 4 | 10696 | 58.46 | 739 | 745 | 170.2 |
| C | 13 | 61 | 6049 | 31.16 | 739 | 745 | 170.2 |
| D | 11 | 145 | 3769486 | 23305.1 | 664 | 646 | 161.7 |
| D | 1 | 239 | 119932 | 737.62 | 664 | 646 | 161.7 |
| D | 8 | 195 | 111804 | 687.36 | 664 | 646 | 161.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
