| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_240T02_9000000670_05257cztM0_level2.evt | modeM0/AS1G05_240T02_9000000670_05257cztM0_level2_quad_clean.evt |
| Size (bytes) | 585,120,960 | 77,978,880 |
| Size | 558.0 MB | 74.4 MB |
| Events in quadrant A | 3,183,210 | 485,061 |
| Events in quadrant B | 3,223,143 | 489,885 |
| Events in quadrant C | 3,321,229 | 477,496 |
| Events in quadrant D | 7,515,914 | 419,244 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 144 | 0 |
| B | 0 | 144 | 0 |
| C | 0 | 144 | 0 |
| D | 0 | 144 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 5 | 0 |
| B | 0 | 5 | 0 |
| C | 0 | 5 | 0 |
| D | 0 | 5 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14528 | 96 |
| B | 0 | 14445 | 100 |
| C | 0 | 14726 | 83 |
| D | 0 | 27529 | 395 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7028 | 120 | 1.707456% |
| B | 7022 | 106 | 1.509541% |
| C | 7032 | 98 | 1.393629% |
| D | 6989 | 1618 | 23.150665% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7581 | 7071 | 6 | 6 | 0.08% | 0.08% |  |
| B | 7581 | 7070 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7581 | 7070 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7581 | 7056 | 1202 | 1202 | 15.86% | 17.04% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 50 | 51849 | 306.11 | 810 | 788 | 166.8 |
| A | 13 | 251 | 15804 | 90.02 | 810 | 788 | 166.8 |
| A | 12 | 194 | 8059 | 43.59 | 810 | 788 | 166.8 |
| B | 0 | 219 | 19433 | 117.41 | 818 | 796 | 158.7 |
| B | 12 | 111 | 15121 | 90.25 | 818 | 796 | 158.7 |
| B | 11 | 111 | 11843 | 69.6 | 818 | 796 | 158.7 |
| C | 1 | 16 | 210498 | 1123.53 | 796 | 797 | 186.6 |
| C | 13 | 61 | 6421 | 30.13 | 796 | 797 | 186.6 |
| C | 8 | 222 | 4091 | 17.65 | 796 | 797 | 186.6 |
| D | 11 | 145 | 4426902 | 25083.48 | 707 | 683 | 176.5 |
| D | 8 | 195 | 177247 | 1000.59 | 707 | 683 | 176.5 |
| D | 2 | 136 | 142031 | 801.02 | 707 | 683 | 176.5 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
