| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_240T02_9000000670_05280cztM0_level2.evt | modeM0/AS1G05_240T02_9000000670_05280cztM0_level2_quad_clean.evt |
| Size (bytes) | 506,263,680 | 79,269,120 |
| Size | 482.8 MB | 75.6 MB |
| Events in quadrant A | 3,135,530 | 500,672 |
| Events in quadrant B | 3,110,677 | 510,844 |
| Events in quadrant C | 2,888,601 | 497,002 |
| Events in quadrant D | 5,765,110 | 447,212 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13657 | 3 |
| B | 0 | 13520 | 2 |
| C | 0 | 12997 | 2 |
| D | 0 | 21581 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6360 | 100 | 1.572327% |
| B | 6360 | 35 | 0.550314% |
| C | 6360 | 13 | 0.204403% |
| D | 6360 | 782 | 12.295597% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7530 | 6361 | 52 | 52 | 0.69% | 0.82% |  |
| B | 7530 | 6361 | 3 | 3 | 0.04% | 0.05% |  |
| C | 7530 | 6361 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7530 | 6360 | 625 | 625 | 8.30% | 9.83% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 50 | 226870 | 1478.51 | 749 | 734 | 152.9 |
| A | 13 | 251 | 26216 | 166.6 | 749 | 734 | 152.9 |
| A | 0 | 226 | 7434 | 43.81 | 749 | 734 | 152.9 |
| B | 4 | 48 | 37523 | 252.64 | 766 | 750 | 145.6 |
| B | 10 | 16 | 32366 | 217.21 | 766 | 750 | 145.6 |
| B | 15 | 204 | 31622 | 212.1 | 766 | 750 | 145.6 |
| C | 1 | 16 | 10224 | 55.42 | 734 | 739 | 171.1 |
| C | 7 | 190 | 9862 | 53.3 | 734 | 739 | 171.1 |
| C | 13 | 61 | 6046 | 31.01 | 734 | 739 | 171.1 |
| D | 11 | 145 | 2749704 | 16074.35 | 687 | 665 | 171.0 |
| D | 8 | 195 | 184164 | 1072.97 | 687 | 665 | 171.0 |
| D | 2 | 136 | 120461 | 700.48 | 687 | 665 | 171.0 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
