| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_021T02_9000000680_05368cztM0_level2.evt | modeM0/AS1G05_021T02_9000000680_05368cztM0_level2_quad_clean.evt |
| Size (bytes) | 445,530,240 | 75,286,080 |
| Size | 424.9 MB | 71.8 MB |
| Events in quadrant A | 3,225,819 | 464,793 |
| Events in quadrant B | 3,250,951 | 478,441 |
| Events in quadrant C | 3,138,702 | 469,610 |
| Events in quadrant D | 3,460,490 | 438,416 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13766 | 3 |
| B | 0 | 13717 | 4 |
| C | 0 | 13588 | 4 |
| D | 0 | 14466 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 124 | 0 |
| B | 0 | 124 | 0 |
| C | 0 | 124 | 0 |
| D | 0 | 124 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 18 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6140 | 120 | 1.954397% |
| B | 6139 | 53 | 0.863333% |
| C | 6139 | 36 | 0.586415% |
| D | 6140 | 112 | 1.824104% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7400 | 6140 | 55 | 55 | 0.74% | 0.90% |  |
| B | 7400 | 6140 | 14 | 14 | 0.19% | 0.23% |  |
| C | 7400 | 6140 | 2 | 2 | 0.03% | 0.03% |  |
| D | 7400 | 6140 | 80 | 80 | 1.08% | 1.30% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 50 | 270547 | 1785.12 | 737 | 724 | 151.2 |
| A | 15 | 174 | 98490 | 646.81 | 737 | 724 | 151.2 |
| A | 14 | 111 | 14428 | 90.66 | 737 | 724 | 151.2 |
| B | 4 | 80 | 121928 | 847.55 | 752 | 735 | 143.0 |
| B | 0 | 219 | 57550 | 397.33 | 752 | 735 | 143.0 |
| B | 10 | 245 | 41986 | 288.48 | 752 | 735 | 143.0 |
| C | 1 | 16 | 305952 | 1854.87 | 715 | 721 | 164.6 |
| C | 9 | 247 | 33132 | 196.96 | 715 | 721 | 164.6 |
| C | 14 | 67 | 9355 | 52.47 | 715 | 721 | 164.6 |
| D | 2 | 136 | 242199 | 1381.7 | 705 | 684 | 174.8 |
| D | 2 | 16 | 180308 | 1027.62 | 705 | 684 | 174.8 |
| D | 4 | 95 | 125564 | 714.43 | 705 | 684 | 174.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
