| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_021T02_9000000680_05371cztM0_level2.evt | modeM0/AS1G05_021T02_9000000680_05371cztM0_level2_quad_clean.evt |
| Size (bytes) | 536,567,040 | 65,819,520 |
| Size | 511.7 MB | 62.8 MB |
| Events in quadrant A | 3,293,582 | 397,300 |
| Events in quadrant B | 3,231,545 | 411,554 |
| Events in quadrant C | 3,285,193 | 407,452 |
| Events in quadrant D | 6,008,769 | 333,334 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13950 | 3 |
| B | 0 | 13755 | 2 |
| C | 0 | 13752 | 2 |
| D | 0 | 22185 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 128 | 0 |
| B | 0 | 128 | 0 |
| C | 0 | 128 | 0 |
| D | 0 | 128 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 23 | 0 |
| B | 0 | 23 | 0 |
| C | 0 | 23 | 0 |
| D | 0 | 24 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6350 | 76 | 1.196850% |
| B | 6350 | 48 | 0.755906% |
| C | 6350 | 25 | 0.393701% |
| D | 6350 | 1310 | 20.629921% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7570 | 6351 | 20 | 20 | 0.26% | 0.31% |  |
| B | 7570 | 6350 | 16 | 16 | 0.21% | 0.25% |  |
| C | 7570 | 6351 | 1 | 1 | 0.01% | 0.02% |  |
| D | 7570 | 6351 | 1248 | 1248 | 16.49% | 19.65% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 50 | 254168 | 1645.1 | 747 | 733 | 154.1 |
| A | 13 | 251 | 96887 | 624.16 | 747 | 733 | 154.1 |
| A | 15 | 174 | 55875 | 357.94 | 747 | 733 | 154.1 |
| B | 4 | 48 | 95239 | 642.35 | 767 | 751 | 147.1 |
| B | 0 | 219 | 38668 | 257.77 | 767 | 751 | 147.1 |
| B | 4 | 80 | 31587 | 209.63 | 767 | 751 | 147.1 |
| C | 1 | 16 | 355046 | 2094.73 | 734 | 739 | 169.1 |
| C | 9 | 247 | 61200 | 357.46 | 734 | 739 | 169.1 |
| C | 13 | 61 | 5850 | 30.22 | 734 | 739 | 169.1 |
| D | 7 | 237 | 3011020 | 19502.6 | 618 | 596 | 154.4 |
| D | 1 | 239 | 367955 | 2379.88 | 618 | 596 | 154.4 |
| D | 2 | 136 | 106830 | 688.22 | 618 | 596 | 154.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
