| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G05_214T01_9000000684_05410cztM0_level2.evt | modeM0/AS1G05_214T01_9000000684_05410cztM0_level2_quad_clean.evt |
| Size (bytes) | 698,428,800 | 72,532,800 |
| Size | 666.1 MB | 69.2 MB |
| Events in quadrant A | 2,940,467 | 480,502 |
| Events in quadrant B | 3,014,756 | 480,314 |
| Events in quadrant C | 2,887,731 | 478,023 |
| Events in quadrant D | 11,889,313 | 323,833 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 126 | 0 |
| B | 0 | 126 | 0 |
| C | 0 | 126 | 0 |
| D | 0 | 126 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13009 | 2 |
| B | 0 | 13126 | 1 |
| C | 0 | 12866 | 1 |
| D | 0 | 39587 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6197 | 80 | 1.290947% |
| B | 6197 | 82 | 1.323221% |
| C | 6197 | 43 | 0.693884% |
| D | 6197 | 3467 | 55.946426% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7277 | 6198 | 13 | 13 | 0.18% | 0.21% |  |
| B | 7277 | 6198 | 8 | 8 | 0.11% | 0.13% |  |
| C | 7277 | 6198 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7277 | 6198 | 3342 | 3342 | 45.93% | 53.92% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 174 | 80231 | 532.4 | 730 | 716 | 149.4 |
| A | 13 | 6 | 19600 | 126.44 | 730 | 716 | 149.4 |
| A | 0 | 247 | 17648 | 113.37 | 730 | 716 | 149.4 |
| B | 15 | 204 | 68019 | 480.06 | 731 | 714 | 140.2 |
| B | 15 | 54 | 36552 | 255.62 | 731 | 714 | 140.2 |
| B | 4 | 48 | 23970 | 165.87 | 731 | 714 | 140.2 |
| C | 1 | 16 | 119222 | 717.88 | 706 | 710 | 165.1 |
| C | 14 | 67 | 9548 | 53.54 | 706 | 710 | 165.1 |
| C | 13 | 61 | 5589 | 29.55 | 706 | 710 | 165.1 |
| D | 2 | 63 | 9458810 | 76694.0 | 506 | 491 | 123.3 |
| D | 2 | 33 | 231203 | 1870.76 | 506 | 491 | 123.3 |
| D | 2 | 152 | 90596 | 730.63 | 506 | 491 | 123.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
