| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A02_162T01_9000000704_05514cztM0_level2.evt | modeM0/AS1A02_162T01_9000000704_05514cztM0_level2_quad_clean.evt |
| Size (bytes) | 581,137,920 | 65,928,960 |
| Size | 554.2 MB | 62.9 MB |
| Events in quadrant A | 2,739,654 | 435,927 |
| Events in quadrant B | 8,547,548 | 312,075 |
| Events in quadrant C | 2,817,490 | 429,389 |
| Events in quadrant D | 3,100,132 | 410,620 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12098 | 2 |
| B | 0 | 29403 | 1 |
| C | 0 | 12428 | 1 |
| D | 0 | 13307 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 118 | 0 |
| B | 0 | 118 | 0 |
| C | 0 | 118 | 0 |
| D | 0 | 118 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5826 | 56 | 0.961208% |
| B | 5826 | 2188 | 37.555784% |
| C | 5826 | 35 | 0.600755% |
| D | 5826 | 64 | 1.098524% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7106 | 5827 | 15 | 15 | 0.21% | 0.26% |  |
| B | 7106 | 5827 | 1941 | 1941 | 27.31% | 33.31% |  |
| C | 7106 | 5827 | 22 | 22 | 0.31% | 0.38% |  |
| D | 7106 | 5827 | 32 | 32 | 0.45% | 0.55% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 0 | 50 | 58624 | 410.01 | 691 | 677 | 141.3 |
| A | 3 | 1 | 9158 | 60.01 | 691 | 677 | 141.3 |
| A | 0 | 226 | 6883 | 43.91 | 691 | 677 | 141.3 |
| B | 15 | 255 | 5660077 | 50592.38 | 593 | 582 | 111.9 |
| B | 15 | 204 | 422175 | 3768.78 | 593 | 582 | 111.9 |
| B | 0 | 219 | 46566 | 411.07 | 593 | 582 | 111.9 |
| C | 1 | 16 | 133997 | 876.64 | 658 | 660 | 152.1 |
| C | 9 | 247 | 103165 | 673.93 | 658 | 660 | 152.1 |
| C | 13 | 61 | 5481 | 31.7 | 658 | 660 | 152.1 |
| D | 2 | 152 | 168688 | 1038.13 | 656 | 634 | 161.9 |
| D | 8 | 195 | 105817 | 649.75 | 656 | 634 | 161.9 |
| D | 2 | 136 | 92433 | 567.07 | 656 | 634 | 161.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
