| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A02_028T01_9000000724_05605cztM0_level2.evt | modeM0/AS1A02_028T01_9000000724_05605cztM0_level2_quad_clean.evt |
| Size (bytes) | 456,868,800 | 77,230,080 |
| Size | 435.7 MB | 73.7 MB |
| Events in quadrant A | 3,272,735 | 469,684 |
| Events in quadrant B | 3,563,124 | 473,275 |
| Events in quadrant C | 3,249,358 | 465,095 |
| Events in quadrant D | 3,278,487 | 446,284 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 144 | 0 |
| B | 0 | 144 | 0 |
| C | 0 | 144 | 0 |
| D | 0 | 144 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14654 | 2 |
| B | 0 | 15269 | 2 |
| C | 0 | 14583 | 2 |
| D | 0 | 14860 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 11 | 0 |
| B | 0 | 11 | 0 |
| C | 0 | 11 | 0 |
| D | 0 | 11 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6954 | 95 | 1.366120% |
| B | 6954 | 122 | 1.754386% |
| C | 6954 | 86 | 1.236698% |
| D | 6954 | 99 | 1.423641% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7979 | 6957 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7979 | 6957 | 0 | 0 | 0.00% | 0.00% |  |
| C | 7979 | 6957 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7979 | 6957 | 10 | 10 | 0.13% | 0.14% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 194 | 8320 | 42.99 | 848 | 829 | 174.3 |
| A | 0 | 226 | 8261 | 42.65 | 848 | 829 | 174.3 |
| A | 3 | 1 | 3057 | 12.78 | 848 | 829 | 174.3 |
| B | 15 | 204 | 248777 | 1494.3 | 852 | 829 | 165.9 |
| B | 0 | 219 | 18865 | 108.7 | 852 | 829 | 165.9 |
| B | 12 | 111 | 15934 | 91.03 | 852 | 829 | 165.9 |
| C | 1 | 16 | 22027 | 109.82 | 826 | 829 | 193.0 |
| C | 13 | 61 | 6652 | 30.17 | 826 | 829 | 193.0 |
| C | 7 | 247 | 2384 | 8.06 | 826 | 829 | 193.0 |
| D | 2 | 136 | 90663 | 443.68 | 824 | 796 | 202.6 |
| D | 2 | 206 | 23233 | 110.77 | 824 | 796 | 202.6 |
| D | 13 | 172 | 21973 | 104.55 | 824 | 796 | 202.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
