| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G06_032T02_9000000730_05636cztM0_level2.evt | modeM0/AS1G06_032T02_9000000730_05636cztM0_level2_quad_clean.evt |
| Size (bytes) | 519,958,080 | 83,963,520 |
| Size | 495.9 MB | 80.1 MB |
| Events in quadrant A | 3,575,887 | 504,418 |
| Events in quadrant B | 4,064,514 | 503,428 |
| Events in quadrant C | 3,555,688 | 514,932 |
| Events in quadrant D | 4,026,388 | 483,038 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 164 | 10 |
| B | 0 | 164 | 8 |
| C | 0 | 164 | 6 |
| D | 0 | 164 | 10 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16956 | 832 |
| B | 0 | 18210 | 837 |
| C | 0 | 16856 | 687 |
| D | 0 | 18812 | 1117 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 7 | 2 |
| B | 0 | 7 | 0 |
| C | 0 | 7 | 0 |
| D | 0 | 7 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7710 | 83 | 1.076524% |
| B | 7709 | 132 | 1.712284% |
| C | 7750 | 63 | 0.812903% |
| D | 7693 | 153 | 1.988821% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8673 | 7977 | 18 | 18 | 0.21% | 0.23% |  |
| B | 8674 | 7981 | 15 | 15 | 0.17% | 0.19% |  |
| C | 8672 | 7998 | 11 | 11 | 0.13% | 0.14% |  |
| D | 8674 | 7966 | 61 | 61 | 0.70% | 0.77% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 14 | 111 | 70224 | 374.46 | 894 | 875 | 185.2 |
| A | 0 | 50 | 19740 | 101.86 | 894 | 875 | 185.2 |
| A | 0 | 254 | 15750 | 80.32 | 894 | 875 | 185.2 |
| B | 15 | 204 | 134293 | 751.96 | 908 | 884 | 177.4 |
| B | 0 | 214 | 113984 | 637.49 | 908 | 884 | 177.4 |
| B | 4 | 48 | 92445 | 516.09 | 908 | 884 | 177.4 |
| C | 5 | 250 | 86969 | 417.76 | 877 | 883 | 206.1 |
| C | 1 | 16 | 24066 | 112.5 | 877 | 883 | 206.1 |
| C | 5 | 233 | 11955 | 53.73 | 877 | 883 | 206.1 |
| D | 2 | 136 | 448296 | 2100.01 | 859 | 831 | 213.1 |
| D | 2 | 152 | 116147 | 541.19 | 859 | 831 | 213.1 |
| D | 2 | 206 | 47659 | 219.77 | 859 | 831 | 213.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
