| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A02_149T01_9000000740_05749cztM0_level2.evt | modeM0/AS1A02_149T01_9000000740_05749cztM0_level2_quad_clean.evt |
| Size (bytes) | 492,180,480 | 80,959,680 |
| Size | 469.4 MB | 77.2 MB |
| Events in quadrant A | 3,507,691 | 484,720 |
| Events in quadrant B | 3,747,588 | 488,078 |
| Events in quadrant C | 3,465,474 | 492,574 |
| Events in quadrant D | 3,680,248 | 469,638 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 14 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 154 | 0 |
| B | 0 | 154 | 0 |
| C | 0 | 154 | 2 |
| D | 0 | 154 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15453 | 28 |
| B | 0 | 15815 | 31 |
| C | 0 | 15443 | 27 |
| D | 0 | 15915 | 38 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7418 | 299 | 4.030736% |
| B | 7417 | 307 | 4.139140% |
| C | 7418 | 217 | 2.925317% |
| D | 7415 | 273 | 3.681726% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8854 | 7430 | 0 | 0 | 0.00% | 0.00% |  |
| B | 8854 | 7431 | 3 | 3 | 0.03% | 0.04% |  |
| C | 8854 | 7431 | 0 | 0 | 0.00% | 0.00% |  |
| D | 8854 | 7430 | 15 | 15 | 0.17% | 0.20% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 236 | 18756 | 95.46 | 905 | 883 | 187.2 |
| A | 0 | 226 | 8855 | 42.58 | 905 | 883 | 187.2 |
| A | 12 | 194 | 8692 | 41.71 | 905 | 883 | 187.2 |
| B | 15 | 204 | 72802 | 405.8 | 909 | 886 | 177.2 |
| B | 11 | 51 | 57580 | 319.91 | 909 | 886 | 177.2 |
| B | 0 | 219 | 33208 | 182.38 | 909 | 886 | 177.2 |
| C | 14 | 67 | 11654 | 52.09 | 883 | 886 | 206.7 |
| C | 13 | 61 | 7147 | 30.28 | 883 | 886 | 206.7 |
| C | 9 | 16 | 5454 | 22.09 | 883 | 886 | 206.7 |
| D | 8 | 195 | 105454 | 480.45 | 885 | 857 | 217.7 |
| D | 12 | 110 | 52388 | 236.7 | 885 | 857 | 217.7 |
| D | 2 | 136 | 30797 | 137.53 | 885 | 857 | 217.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
