| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G06_002T01_9000000742_05772cztM0_level2.evt | modeM0/AS1G06_002T01_9000000742_05772cztM0_level2_quad_clean.evt |
| Size (bytes) | 412,185,600 | 74,969,280 |
| Size | 393.1 MB | 71.5 MB |
| Events in quadrant A | 2,961,801 | 454,928 |
| Events in quadrant B | 3,113,128 | 462,599 |
| Events in quadrant C | 2,971,947 | 456,198 |
| Events in quadrant D | 2,988,759 | 437,930 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13322 | 3 |
| B | 0 | 13499 | 2 |
| C | 0 | 13334 | 2 |
| D | 0 | 13460 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 19 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6579 | 12 | 0.182399% |
| B | 6579 | 35 | 0.531996% |
| C | 6579 | 29 | 0.440796% |
| D | 6579 | 23 | 0.349597% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7729 | 6580 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7729 | 6580 | 2 | 2 | 0.03% | 0.03% |  |
| C | 7729 | 6580 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7729 | 6580 | 4 | 4 | 0.05% | 0.06% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 194 | 7503 | 42.48 | 769 | 753 | 158.9 |
| A | 0 | 226 | 7442 | 42.09 | 769 | 753 | 158.9 |
| A | 13 | 254 | 2561 | 11.38 | 769 | 753 | 158.9 |
| B | 15 | 204 | 28667 | 187.23 | 784 | 762 | 149.0 |
| B | 4 | 81 | 23985 | 155.82 | 784 | 762 | 149.0 |
| B | 0 | 219 | 15901 | 101.57 | 784 | 762 | 149.0 |
| C | 13 | 61 | 6115 | 30.21 | 761 | 764 | 177.2 |
| C | 8 | 222 | 2323 | 8.8 | 761 | 764 | 177.2 |
| C | 3 | 202 | 1967 | 6.79 | 761 | 764 | 177.2 |
| D | 12 | 221 | 73254 | 395.72 | 750 | 726 | 183.3 |
| D | 6 | 223 | 27653 | 146.91 | 750 | 726 | 183.3 |
| D | 2 | 14 | 17091 | 89.29 | 750 | 726 | 183.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
