| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A02_106T01_9000000744_05799cztM0_level2.evt | modeM0/AS1A02_106T01_9000000744_05799cztM0_level2_quad_clean.evt |
| Size (bytes) | 429,960,960 | 82,296,000 |
| Size | 410.0 MB | 78.5 MB |
| Events in quadrant A | 2,996,708 | 508,113 |
| Events in quadrant B | 3,203,961 | 515,144 |
| Events in quadrant C | 3,014,121 | 511,173 |
| Events in quadrant D | 3,348,039 | 487,645 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 18 | 0 |
| B | 0 | 18 | 0 |
| C | 0 | 18 | 0 |
| D | 0 | 18 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13792 | 3 |
| B | 0 | 14279 | 2 |
| C | 0 | 13800 | 2 |
| D | 0 | 14821 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 138 | 0 |
| B | 0 | 138 | 0 |
| C | 0 | 138 | 0 |
| D | 0 | 138 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6745 | 57 | 0.845070% |
| B | 6745 | 72 | 1.067457% |
| C | 6745 | 40 | 0.593032% |
| D | 6745 | 52 | 0.770941% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8565 | 6747 | 0 | 0 | 0.00% | 0.00% |  |
| B | 8565 | 6747 | 1 | 1 | 0.01% | 0.01% |  |
| C | 8565 | 6747 | 0 | 0 | 0.00% | 0.00% |  |
| D | 8565 | 6747 | 14 | 14 | 0.16% | 0.21% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 12 | 194 | 7443 | 41.77 | 775 | 757 | 160.1 |
| A | 0 | 226 | 7432 | 41.7 | 775 | 757 | 160.1 |
| A | 13 | 14 | 6074 | 33.22 | 775 | 757 | 160.1 |
| B | 15 | 204 | 66039 | 428.86 | 789 | 768 | 152.2 |
| B | 4 | 81 | 51506 | 333.37 | 789 | 768 | 152.2 |
| B | 0 | 219 | 19273 | 121.59 | 789 | 768 | 152.2 |
| C | 8 | 128 | 8328 | 42.28 | 764 | 767 | 178.8 |
| C | 14 | 67 | 7967 | 40.27 | 764 | 767 | 178.8 |
| C | 13 | 61 | 6193 | 30.34 | 764 | 767 | 178.8 |
| D | 11 | 241 | 233311 | 1244.57 | 758 | 736 | 186.9 |
| D | 12 | 233 | 99728 | 529.73 | 758 | 736 | 186.9 |
| D | 7 | 55 | 48995 | 258.25 | 758 | 736 | 186.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
