| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G06_033T01_9000000760_05855cztM0_level2.evt | modeM0/AS1G06_033T01_9000000760_05855cztM0_level2_quad_clean.evt |
| Size (bytes) | 46,681,920 | 11,914,560 |
| Size | 44.5 MB | 11.4 MB |
| Events in quadrant A | 316,930 | 75,463 |
| Events in quadrant B | 343,537 | 75,875 |
| Events in quadrant C | 321,200 | 76,584 |
| Events in quadrant D | 379,083 | 73,895 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 2 |
| B | 0 | 16 | 0 |
| C | 0 | 16 | 0 |
| D | 0 | 16 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 1483 | 33 |
| B | 0 | 1514 | 28 |
| C | 0 | 1486 | 22 |
| D | 0 | 1590 | 24 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 724 | 0 | 0.000000% |
| B | 726 | 1 | 0.137741% |
| C | 729 | 0 | 0.000000% |
| D | 728 | 0 | 0.000000% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 740 | 737 | 0 | 0 | 0.00% | 0.00% |  |
| B | 740 | 738 | 0 | 0 | 0.00% | 0.00% |  |
| C | 740 | 740 | 0 | 0 | 0.00% | 0.00% |  |
| D | 739 | 738 | 0 | 0 | 0.00% | 0.00% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 234 | 1491 | 73.77 | 81 | 79 | 19.1 |
| A | 12 | 194 | 870 | 41.32 | 81 | 79 | 19.1 |
| A | 0 | 226 | 816 | 38.5 | 81 | 79 | 19.1 |
| B | 0 | 219 | 8219 | 446.0 | 82 | 81 | 18.2 |
| B | 15 | 85 | 4249 | 228.43 | 82 | 81 | 18.2 |
| B | 0 | 214 | 3745 | 200.81 | 82 | 81 | 18.2 |
| C | 8 | 128 | 2058 | 93.98 | 81 | 81 | 21.0 |
| C | 8 | 112 | 1028 | 45.02 | 81 | 81 | 21.0 |
| C | 8 | 144 | 771 | 32.8 | 81 | 81 | 21.0 |
| D | 1 | 239 | 27718 | 1261.65 | 81 | 78 | 21.9 |
| D | 2 | 152 | 11671 | 529.17 | 81 | 78 | 21.9 |
| D | 1 | 20 | 9811 | 444.27 | 81 | 78 | 21.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
