| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G06_023T01_9000000762_05876cztM0_level2.evt | modeM0/AS1G06_023T01_9000000762_05876cztM0_level2_quad_clean.evt |
| Size (bytes) | 474,808,320 | 85,464,000 |
| Size | 452.8 MB | 81.5 MB |
| Events in quadrant A | 3,028,895 | 548,543 |
| Events in quadrant B | 3,416,815 | 559,649 |
| Events in quadrant C | 2,857,540 | 541,022 |
| Events in quadrant D | 4,639,003 | 489,543 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13482 | 3 |
| B | 0 | 14511 | 2 |
| C | 0 | 13131 | 2 |
| D | 0 | 18354 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 18 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6441 | 22 | 0.341562% |
| B | 6441 | 88 | 1.366247% |
| C | 6441 | 18 | 0.279460% |
| D | 6441 | 277 | 4.300574% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7731 | 6442 | 3 | 3 | 0.04% | 0.05% |  |
| B | 7731 | 6442 | 39 | 39 | 0.50% | 0.61% |  |
| C | 7731 | 6442 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7731 | 6442 | 195 | 195 | 2.52% | 3.03% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 234 | 73786 | 483.28 | 748 | 733 | 151.2 |
| A | 15 | 236 | 57439 | 375.14 | 748 | 733 | 151.2 |
| A | 8 | 6 | 18489 | 117.46 | 748 | 733 | 151.2 |
| B | 8 | 3 | 185048 | 1281.51 | 763 | 747 | 143.8 |
| B | 4 | 81 | 117683 | 813.1 | 763 | 747 | 143.8 |
| B | 15 | 204 | 57167 | 392.31 | 763 | 747 | 143.8 |
| C | 1 | 16 | 8375 | 45.66 | 728 | 733 | 167.4 |
| C | 13 | 61 | 5822 | 30.4 | 728 | 733 | 167.4 |
| C | 12 | 4 | 5563 | 28.86 | 728 | 733 | 167.4 |
| D | 2 | 152 | 897862 | 5148.09 | 706 | 683 | 174.3 |
| D | 13 | 105 | 463050 | 2653.1 | 706 | 683 | 174.3 |
| D | 2 | 136 | 313814 | 1796.77 | 706 | 683 | 174.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
