| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A02_114T01_9000000764_05890cztM0_level2.evt | modeM0/AS1A02_114T01_9000000764_05890cztM0_level2_quad_clean.evt |
| Size (bytes) | 452,903,040 | 83,376,000 |
| Size | 431.9 MB | 79.5 MB |
| Events in quadrant A | 2,939,830 | 520,371 |
| Events in quadrant B | 3,144,717 | 538,058 |
| Events in quadrant C | 3,016,467 | 525,473 |
| Events in quadrant D | 4,176,013 | 489,946 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14 | 0 |
| B | 0 | 14 | 0 |
| C | 0 | 14 | 0 |
| D | 0 | 15 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13166 | 3 |
| B | 0 | 13534 | 2 |
| C | 0 | 13215 | 2 |
| D | 0 | 16557 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6462 | 16 | 0.247601% |
| B | 6462 | 26 | 0.402352% |
| C | 6462 | 11 | 0.170226% |
| D | 6462 | 84 | 1.299907% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7737 | 6463 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7737 | 6463 | 1 | 1 | 0.01% | 0.02% |  |
| C | 7737 | 6463 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7737 | 6463 | 40 | 40 | 0.52% | 0.62% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 7 | 16 | 10417 | 62.65 | 760 | 746 | 154.4 |
| A | 0 | 226 | 7346 | 42.76 | 760 | 746 | 154.4 |
| A | 12 | 194 | 7283 | 42.35 | 760 | 746 | 154.4 |
| B | 15 | 204 | 71273 | 479.7 | 780 | 761 | 147.0 |
| B | 4 | 200 | 19921 | 130.35 | 780 | 761 | 147.0 |
| B | 15 | 255 | 14711 | 94.9 | 780 | 761 | 147.0 |
| C | 14 | 206 | 31658 | 176.08 | 759 | 765 | 175.4 |
| C | 1 | 16 | 9432 | 49.4 | 759 | 765 | 175.4 |
| C | 8 | 128 | 6350 | 31.83 | 759 | 765 | 175.4 |
| D | 2 | 152 | 558288 | 3113.69 | 740 | 720 | 179.1 |
| D | 1 | 20 | 469110 | 2615.68 | 740 | 720 | 179.1 |
| D | 2 | 136 | 181181 | 1007.77 | 740 | 720 | 179.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
