| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A02_114T01_9000000764_05903cztM0_level2.evt | modeM0/AS1A02_114T01_9000000764_05903cztM0_level2_quad_clean.evt |
| Size (bytes) | 447,690,240 | 89,043,840 |
| Size | 427.0 MB | 84.9 MB |
| Events in quadrant A | 3,280,982 | 551,853 |
| Events in quadrant B | 3,430,276 | 559,310 |
| Events in quadrant C | 3,139,416 | 547,320 |
| Events in quadrant D | 3,210,607 | 529,314 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16 | 0 |
| B | 0 | 16 | 0 |
| C | 0 | 16 | 0 |
| D | 0 | 17 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 148 | 0 |
| B | 0 | 148 | 0 |
| C | 0 | 148 | 0 |
| D | 0 | 148 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15136 | 3 |
| B | 0 | 15260 | 2 |
| C | 0 | 14776 | 2 |
| D | 0 | 15106 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7307 | 27 | 0.369509% |
| B | 7307 | 35 | 0.478993% |
| C | 7307 | 12 | 0.164226% |
| D | 7307 | 20 | 0.273710% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 31253 | 7309 | 6 | 6 | 0.02% | 0.08% |  |
| B | 31253 | 7309 | 0 | 0 | 0.00% | 0.00% |  |
| C | 31253 | 7309 | 0 | 0 | 0.00% | 0.00% |  |
| D | 31253 | 7309 | 9 | 9 | 0.03% | 0.12% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 236 | 81392 | 478.06 | 820 | 801 | 168.6 |
| A | 15 | 234 | 30707 | 177.4 | 820 | 801 | 168.6 |
| A | 7 | 16 | 12020 | 66.55 | 820 | 801 | 168.6 |
| B | 15 | 204 | 122111 | 750.34 | 838 | 816 | 161.7 |
| B | 4 | 80 | 48445 | 294.64 | 838 | 816 | 161.7 |
| B | 12 | 111 | 15715 | 92.17 | 838 | 816 | 161.7 |
| C | 14 | 67 | 8941 | 43.74 | 801 | 805 | 186.0 |
| C | 13 | 61 | 6534 | 30.8 | 801 | 805 | 186.0 |
| C | 1 | 16 | 5180 | 23.52 | 801 | 805 | 186.0 |
| D | 2 | 152 | 67771 | 345.23 | 791 | 765 | 194.1 |
| D | 2 | 14 | 48141 | 244.09 | 791 | 765 | 194.1 |
| D | 8 | 195 | 21511 | 106.89 | 791 | 765 | 194.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
