| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A02_174T01_9000000766_05906cztM0_level2.evt | modeM0/AS1A02_174T01_9000000766_05906cztM0_level2_quad_clean.evt |
| Size (bytes) | 451,074,240 | 66,749,760 |
| Size | 430.2 MB | 63.7 MB |
| Events in quadrant A | 3,164,557 | 391,309 |
| Events in quadrant B | 3,496,759 | 398,358 |
| Events in quadrant C | 3,120,791 | 389,383 |
| Events in quadrant D | 3,416,061 | 367,765 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 26 | 0 |
| B | 0 | 26 | 0 |
| C | 0 | 26 | 0 |
| D | 0 | 26 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14137 | 3 |
| B | 0 | 14924 | 2 |
| C | 0 | 14002 | 2 |
| D | 0 | 15109 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 138 | 0 |
| B | 0 | 138 | 0 |
| C | 0 | 138 | 0 |
| D | 0 | 138 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6811 | 46 | 0.675378% |
| B | 6811 | 85 | 1.247981% |
| C | 6811 | 18 | 0.264278% |
| D | 6811 | 46 | 0.675378% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 9371 | 6813 | 1 | 1 | 0.01% | 0.01% |  |
| B | 9371 | 6813 | 3 | 3 | 0.03% | 0.04% |  |
| C | 9371 | 6813 | 0 | 0 | 0.00% | 0.00% |  |
| D | 9371 | 6813 | 33 | 33 | 0.35% | 0.48% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 236 | 26482 | 156.88 | 811 | 793 | 163.7 |
| A | 15 | 234 | 12709 | 72.77 | 811 | 793 | 163.7 |
| A | 0 | 226 | 7898 | 43.39 | 811 | 793 | 163.7 |
| B | 0 | 214 | 77344 | 483.12 | 827 | 805 | 158.4 |
| B | 15 | 204 | 61171 | 381.04 | 827 | 805 | 158.4 |
| B | 4 | 81 | 55175 | 343.19 | 827 | 805 | 158.4 |
| C | 9 | 247 | 14076 | 72.03 | 794 | 799 | 184.3 |
| C | 13 | 61 | 6369 | 30.22 | 794 | 799 | 184.3 |
| C | 12 | 4 | 5122 | 23.45 | 794 | 799 | 184.3 |
| D | 2 | 152 | 297584 | 1540.58 | 782 | 757 | 192.7 |
| D | 10 | 40 | 45430 | 231.86 | 782 | 757 | 192.7 |
| D | 2 | 14 | 28569 | 144.35 | 782 | 757 | 192.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
