| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G06_027T01_9000000770_05944cztM0_level2.evt | modeM0/AS1G06_027T01_9000000770_05944cztM0_level2_quad_clean.evt |
| Size (bytes) | 892,324,800 | 123,543,360 |
| Size | 851.0 MB | 117.8 MB |
| Events in quadrant A | 6,261,190 | 756,589 |
| Events in quadrant B | 5,177,484 | 789,882 |
| Events in quadrant C | 4,770,442 | 790,115 |
| Events in quadrant D | 10,102,630 | 675,612 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 27864 | 2259 |
| B | 0 | 23989 | 1605 |
| C | 0 | 23284 | 1489 |
| D | 0 | 42498 | 5528 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 1 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 232 | 12 |
| B | 0 | 232 | 18 |
| C | 0 | 232 | 18 |
| D | 0 | 232 | 16 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 10536 | 540 | 5.125285% |
| B | 10638 | 109 | 1.024629% |
| C | 10655 | 40 | 0.375411% |
| D | 10180 | 1283 | 12.603143% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 11892 | 11225 | 295 | 295 | 2.48% | 2.63% |  |
| B | 11892 | 11254 | 2 | 2 | 0.02% | 0.02% |  |
| C | 11892 | 11270 | 1 | 1 | 0.01% | 0.01% |  |
| D | 11891 | 11036 | 1054 | 1054 | 8.86% | 9.55% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 4 | 2 | 1260533 | 5104.99 | 1207 | 1180 | 246.7 |
| A | 8 | 192 | 149069 | 599.49 | 1207 | 1180 | 246.7 |
| A | 15 | 234 | 87179 | 348.61 | 1207 | 1180 | 246.7 |
| B | 0 | 214 | 96751 | 394.44 | 1249 | 1222 | 242.2 |
| B | 15 | 204 | 90418 | 368.29 | 1249 | 1222 | 242.2 |
| B | 0 | 219 | 86284 | 351.22 | 1249 | 1222 | 242.2 |
| C | 1 | 16 | 25558 | 86.6 | 1202 | 1210 | 281.1 |
| C | 8 | 128 | 22192 | 74.63 | 1202 | 1210 | 281.1 |
| C | 8 | 112 | 11297 | 35.88 | 1202 | 1210 | 281.1 |
| D | 1 | 20 | 4340543 | 16085.95 | 1091 | 1059 | 269.8 |
| D | 2 | 63 | 1167451 | 4323.68 | 1091 | 1059 | 269.8 |
| D | 2 | 14 | 245954 | 907.8 | 1091 | 1059 | 269.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
