| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G06_130T01_9000000782_06066cztM0_level2.evt | modeM0/AS1G06_130T01_9000000782_06066cztM0_level2_quad_clean.evt |
| Size (bytes) | 476,951,040 | 124,776,000 |
| Size | 454.9 MB | 119.0 MB |
| Events in quadrant A | 3,201,108 | 832,737 |
| Events in quadrant B | 4,000,986 | 841,239 |
| Events in quadrant C | 3,010,448 | 835,170 |
| Events in quadrant D | 3,761,798 | 787,924 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 142 | 0 |
| B | 0 | 142 | 0 |
| C | 0 | 142 | 0 |
| D | 0 | 142 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 17 | 0 |
| B | 0 | 17 | 0 |
| C | 0 | 17 | 0 |
| D | 0 | 18 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14530 | 3 |
| B | 0 | 16716 | 2 |
| C | 0 | 14125 | 2 |
| D | 0 | 16289 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6913 | 38 | 0.549689% |
| B | 6913 | 221 | 3.196875% |
| C | 6913 | 25 | 0.361637% |
| D | 6913 | 136 | 1.967308% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7983 | 6914 | 1 | 1 | 0.01% | 0.01% |  |
| B | 7983 | 6914 | 103 | 103 | 1.29% | 1.49% |  |
| C | 7983 | 6914 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7983 | 6914 | 67 | 67 | 0.84% | 0.97% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 185487 | 1181.07 | 774 | 757 | 156.4 |
| A | 14 | 111 | 13806 | 83.43 | 774 | 757 | 156.4 |
| A | 0 | 50 | 9871 | 58.27 | 774 | 757 | 156.4 |
| B | 3 | 64 | 630266 | 4206.41 | 788 | 768 | 149.7 |
| B | 4 | 81 | 101014 | 669.86 | 788 | 768 | 149.7 |
| B | 0 | 214 | 73800 | 488.01 | 788 | 768 | 149.7 |
| C | 9 | 54 | 17881 | 97.61 | 762 | 764 | 175.4 |
| C | 1 | 16 | 14191 | 76.57 | 762 | 764 | 175.4 |
| C | 13 | 61 | 6221 | 31.12 | 762 | 764 | 175.4 |
| D | 12 | 221 | 385437 | 2098.89 | 747 | 721 | 183.3 |
| D | 13 | 169 | 356339 | 1940.14 | 747 | 721 | 183.3 |
| D | 2 | 33 | 61842 | 333.45 | 747 | 721 | 183.3 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
