| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G06_033T01_9000000792_06109cztM0_level2.evt | modeM0/AS1G06_033T01_9000000792_06109cztM0_level2_quad_clean.evt |
| Size (bytes) | 402,330,240 | 65,862,720 |
| Size | 383.7 MB | 62.8 MB |
| Events in quadrant A | 2,746,164 | 399,503 |
| Events in quadrant B | 3,118,875 | 406,447 |
| Events in quadrant C | 2,679,825 | 401,687 |
| Events in quadrant D | 3,246,135 | 382,141 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12072 | 4 |
| B | 0 | 12978 | 8 |
| C | 0 | 11923 | 1 |
| D | 0 | 13817 | 3 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 118 | 0 |
| B | 0 | 118 | 0 |
| C | 0 | 118 | 0 |
| D | 0 | 118 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5783 | 25 | 0.432302% |
| B | 5783 | 62 | 1.072108% |
| C | 5784 | 20 | 0.345781% |
| D | 5783 | 120 | 2.075048% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7059 | 5784 | 1 | 1 | 0.01% | 0.02% |  |
| B | 7059 | 5785 | 23 | 23 | 0.33% | 0.40% |  |
| C | 7059 | 5785 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7059 | 5785 | 47 | 47 | 0.67% | 0.81% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 13 | 251 | 63613 | 451.57 | 681 | 665 | 139.4 |
| A | 8 | 15 | 53058 | 375.85 | 681 | 665 | 139.4 |
| A | 12 | 194 | 6602 | 42.59 | 681 | 665 | 139.4 |
| B | 3 | 64 | 222130 | 1655.54 | 694 | 677 | 133.8 |
| B | 15 | 204 | 116391 | 865.06 | 694 | 677 | 133.8 |
| B | 5 | 143 | 21346 | 154.52 | 694 | 677 | 133.8 |
| C | 1 | 16 | 41318 | 258.49 | 672 | 676 | 157.2 |
| C | 9 | 54 | 17171 | 104.91 | 672 | 676 | 157.2 |
| C | 13 | 61 | 5306 | 29.45 | 672 | 676 | 157.2 |
| D | 13 | 169 | 577592 | 3531.47 | 664 | 645 | 163.4 |
| D | 2 | 33 | 58801 | 355.97 | 664 | 645 | 163.4 |
| D | 7 | 55 | 21454 | 127.37 | 664 | 645 | 163.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
