| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G06_019T01_9000000796_06126cztM0_level2.evt | modeM0/AS1G06_019T01_9000000796_06126cztM0_level2_quad_clean.evt |
| Size (bytes) | 608,313,600 | 90,115,200 |
| Size | 580.1 MB | 85.9 MB |
| Events in quadrant A | 7,885,043 | 542,454 |
| Events in quadrant B | 3,456,821 | 571,207 |
| Events in quadrant C | 3,234,563 | 562,463 |
| Events in quadrant D | 3,352,911 | 545,336 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3 | 0 |
| B | 0 | 3 | 0 |
| C | 0 | 3 | 0 |
| D | 0 | 3 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 28462 | 98 |
| B | 0 | 15344 | 51 |
| C | 0 | 14859 | 27 |
| D | 0 | 15420 | 20 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 148 | 0 |
| B | 0 | 148 | 2 |
| C | 0 | 148 | 0 |
| D | 0 | 148 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7285 | 609 | 8.359643% |
| B | 7287 | 47 | 0.644984% |
| C | 7292 | 23 | 0.315414% |
| D | 7296 | 63 | 0.863487% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7590 | 7305 | 685 | 685 | 9.03% | 9.38% |  |
| B | 7590 | 7305 | 5 | 5 | 0.07% | 0.07% |  |
| C | 7590 | 7306 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7590 | 7306 | 32 | 32 | 0.42% | 0.44% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 4709102 | 28284.98 | 818 | 799 | 166.5 |
| A | 4 | 2 | 18179 | 104.41 | 818 | 799 | 166.5 |
| A | 12 | 194 | 7892 | 42.61 | 818 | 799 | 166.5 |
| B | 3 | 64 | 68565 | 414.52 | 843 | 822 | 163.4 |
| B | 15 | 204 | 31250 | 186.19 | 843 | 822 | 163.4 |
| B | 8 | 3 | 24589 | 145.43 | 843 | 822 | 163.4 |
| C | 9 | 68 | 33691 | 172.48 | 813 | 818 | 190.6 |
| C | 1 | 16 | 18394 | 92.22 | 813 | 818 | 190.6 |
| C | 13 | 61 | 6531 | 29.98 | 813 | 818 | 190.6 |
| D | 13 | 169 | 101229 | 505.09 | 809 | 785 | 198.9 |
| D | 13 | 105 | 42154 | 208.03 | 809 | 785 | 198.9 |
| D | 7 | 55 | 41554 | 205.01 | 809 | 785 | 198.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
