| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A02_152T01_9000000806_06183cztM0_level2.evt | modeM0/AS1A02_152T01_9000000806_06183cztM0_level2_quad_clean.evt |
| Size (bytes) | 414,590,400 | 93,216,960 |
| Size | 395.4 MB | 88.9 MB |
| Events in quadrant A | 2,988,757 | 605,050 |
| Events in quadrant B | 3,150,872 | 609,312 |
| Events in quadrant C | 2,872,932 | 589,134 |
| Events in quadrant D | 3,096,699 | 562,923 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 146 | 16 |
| B | 0 | 146 | 10 |
| C | 0 | 146 | 12 |
| D | 0 | 146 | 2 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14840 | 1391 |
| B | 0 | 15545 | 1710 |
| C | 0 | 14722 | 1364 |
| D | 0 | 15728 | 1677 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9 | 1 |
| B | 0 | 9 | 0 |
| C | 0 | 9 | 1 |
| D | 0 | 10 | 1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6549 | 36 | 0.549702% |
| B | 6511 | 46 | 0.706497% |
| C | 6554 | 8 | 0.122063% |
| D | 6496 | 48 | 0.738916% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 8000 | 7110 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7999 | 7095 | 8 | 8 | 0.10% | 0.11% |  |
| C | 7999 | 7107 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7999 | 7088 | 42 | 42 | 0.53% | 0.59% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 55612 | 353.86 | 759 | 745 | 155.1 |
| A | 0 | 226 | 7330 | 42.47 | 759 | 745 | 155.1 |
| A | 12 | 194 | 7160 | 41.37 | 759 | 745 | 155.1 |
| B | 3 | 64 | 133318 | 907.48 | 763 | 747 | 146.1 |
| B | 4 | 80 | 26987 | 179.62 | 763 | 747 | 146.1 |
| B | 0 | 219 | 16427 | 107.33 | 763 | 747 | 146.1 |
| C | 1 | 16 | 13871 | 77.26 | 731 | 736 | 170.0 |
| C | 13 | 61 | 5862 | 30.15 | 731 | 736 | 170.0 |
| C | 14 | 67 | 3543 | 16.51 | 731 | 736 | 170.0 |
| D | 2 | 136 | 172468 | 968.08 | 720 | 700 | 177.4 |
| D | 10 | 172 | 109715 | 614.41 | 720 | 700 | 177.4 |
| D | 2 | 14 | 31895 | 175.81 | 720 | 700 | 177.4 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
