| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A02_118T01_9000000826_06285cztM0_level2.evt | modeM0/AS1A02_118T01_9000000826_06285cztM0_level2_quad_clean.evt |
| Size (bytes) | 552,545,280 | 112,487,040 |
| Size | 526.9 MB | 107.3 MB |
| Events in quadrant A | 4,113,745 | 731,251 |
| Events in quadrant B | 4,391,702 | 732,369 |
| Events in quadrant C | 3,101,558 | 736,169 |
| Events in quadrant D | 4,635,381 | 702,403 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 6 | 0 |
| B | 0 | 6 | 0 |
| C | 0 | 6 | 0 |
| D | 0 | 7 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 146 | 0 |
| B | 0 | 146 | 0 |
| C | 0 | 146 | 0 |
| D | 0 | 146 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 16889 | 3 |
| B | 0 | 18123 | 2 |
| C | 0 | 14742 | 2 |
| D | 0 | 18661 | 2 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7249 | 106 | 1.462271% |
| B | 7249 | 392 | 5.407642% |
| C | 7249 | 15 | 0.206925% |
| D | 7249 | 183 | 2.524486% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7714 | 7250 | 2 | 2 | 0.03% | 0.03% |  |
| B | 7714 | 7249 | 160 | 160 | 2.07% | 2.21% |  |
| C | 7714 | 7250 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7713 | 7249 | 142 | 142 | 1.84% | 1.96% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 891874 | 5323.86 | 816 | 797 | 167.4 |
| A | 15 | 174 | 48287 | 283.74 | 816 | 797 | 167.4 |
| A | 15 | 236 | 16341 | 92.87 | 816 | 797 | 167.4 |
| B | 3 | 64 | 455786 | 2957.96 | 810 | 789 | 153.8 |
| B | 0 | 219 | 339545 | 2202.27 | 810 | 789 | 153.8 |
| B | 4 | 81 | 188091 | 1217.66 | 810 | 789 | 153.8 |
| C | 1 | 16 | 8327 | 41.06 | 791 | 794 | 183.4 |
| C | 13 | 61 | 6486 | 31.03 | 791 | 794 | 183.4 |
| C | 8 | 222 | 4203 | 18.58 | 791 | 794 | 183.4 |
| D | 12 | 220 | 826462 | 4306.08 | 784 | 756 | 191.8 |
| D | 12 | 110 | 236011 | 1226.86 | 784 | 756 | 191.8 |
| D | 2 | 152 | 207913 | 1080.33 | 784 | 756 | 191.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
