| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A02_124T01_9000000842_06358cztM0_level2.evt | modeM0/AS1A02_124T01_9000000842_06358cztM0_level2_quad_clean.evt |
| Size (bytes) | 507,548,160 | 104,080,320 |
| Size | 484.0 MB | 99.3 MB |
| Events in quadrant A | 3,611,937 | 665,556 |
| Events in quadrant B | 3,619,334 | 669,183 |
| Events in quadrant C | 3,394,213 | 662,800 |
| Events in quadrant D | 4,237,779 | 634,142 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 3 | 0 |
| B | 0 | 3 | 0 |
| C | 0 | 3 | 0 |
| D | 0 | 3 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15757 | 2 |
| B | 0 | 15878 | 1 |
| C | 0 | 15607 | 1 |
| D | 0 | 17708 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 152 | 0 |
| B | 0 | 152 | 0 |
| C | 0 | 152 | 0 |
| D | 0 | 152 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 7482 | 52 | 0.695001% |
| B | 7482 | 68 | 0.908848% |
| C | 7482 | 32 | 0.427693% |
| D | 7482 | 189 | 2.526063% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7697 | 7484 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7697 | 7484 | 11 | 11 | 0.14% | 0.15% |  |
| C | 7697 | 7484 | 3 | 3 | 0.04% | 0.04% |  |
| D | 7697 | 7484 | 141 | 141 | 1.83% | 1.88% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 236 | 238535 | 1356.5 | 856 | 836 | 175.2 |
| A | 13 | 251 | 39013 | 217.87 | 856 | 836 | 175.2 |
| A | 8 | 15 | 22235 | 122.12 | 856 | 836 | 175.2 |
| B | 10 | 246 | 66213 | 392.85 | 863 | 840 | 166.4 |
| B | 0 | 214 | 60139 | 356.35 | 863 | 840 | 166.4 |
| B | 15 | 204 | 43794 | 258.12 | 863 | 840 | 166.4 |
| C | 4 | 254 | 134260 | 692.9 | 829 | 831 | 192.6 |
| C | 1 | 241 | 13928 | 68.01 | 829 | 831 | 192.6 |
| C | 13 | 61 | 6573 | 29.82 | 829 | 831 | 192.6 |
| D | 12 | 220 | 466817 | 2298.21 | 823 | 797 | 202.8 |
| D | 11 | 241 | 204880 | 1006.45 | 823 | 797 | 202.8 |
| D | 2 | 63 | 179322 | 880.41 | 823 | 797 | 202.8 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
