| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A02_124T01_9000000842_06366cztM0_level2.evt | modeM0/AS1A02_124T01_9000000842_06366cztM0_level2_quad_clean.evt |
| Size (bytes) | 475,257,600 | 85,936,320 |
| Size | 453.2 MB | 82.0 MB |
| Events in quadrant A | 3,308,191 | 542,719 |
| Events in quadrant B | 4,374,648 | 544,974 |
| Events in quadrant C | 3,057,590 | 546,433 |
| Events in quadrant D | 3,217,651 | 521,177 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 19 | 0 |
| B | 0 | 19 | 0 |
| C | 0 | 19 | 0 |
| D | 0 | 20 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13933 | 3 |
| B | 0 | 17062 | 2 |
| C | 0 | 13278 | 2 |
| D | 0 | 13893 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 130 | 0 |
| B | 0 | 130 | 0 |
| C | 0 | 130 | 0 |
| D | 0 | 130 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6407 | 50 | 0.780396% |
| B | 6407 | 361 | 5.634462% |
| C | 6407 | 55 | 0.858436% |
| D | 6407 | 89 | 1.389106% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7556 | 6407 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7556 | 6407 | 228 | 228 | 3.02% | 3.56% |  |
| C | 7557 | 6408 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7556 | 6407 | 30 | 30 | 0.40% | 0.47% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 236 | 300246 | 1915.15 | 772 | 755 | 156.4 |
| A | 8 | 15 | 16043 | 97.76 | 772 | 755 | 156.4 |
| A | 13 | 251 | 14122 | 85.48 | 772 | 755 | 156.4 |
| B | 0 | 228 | 1068351 | 7402.31 | 770 | 753 | 144.2 |
| B | 5 | 250 | 207887 | 1436.19 | 770 | 753 | 144.2 |
| B | 15 | 204 | 39596 | 269.32 | 770 | 753 | 144.2 |
| C | 4 | 254 | 44111 | 245.42 | 767 | 770 | 176.6 |
| C | 5 | 175 | 9017 | 46.7 | 767 | 770 | 176.6 |
| C | 9 | 54 | 8293 | 42.6 | 767 | 770 | 176.6 |
| D | 2 | 152 | 206761 | 1120.04 | 758 | 735 | 183.9 |
| D | 11 | 241 | 92015 | 496.23 | 758 | 735 | 183.9 |
| D | 2 | 63 | 17621 | 91.8 | 758 | 735 | 183.9 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
