| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1C02_011T01_9000000850_06406cztM0_level2.evt | modeM0/AS1C02_011T01_9000000850_06406cztM0_level2_quad_clean.evt |
| Size (bytes) | 965,148,480 | 168,543,360 |
| Size | 920.4 MB | 160.7 MB |
| Events in quadrant A | 6,693,965 | 1,036,086 |
| Events in quadrant B | 7,231,669 | 1,043,283 |
| Events in quadrant C | 7,619,901 | 1,046,689 |
| Events in quadrant D | 6,733,872 | 1,009,027 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 290 | 0 |
| B | 0 | 290 | 0 |
| C | 0 | 290 | 0 |
| D | 0 | 290 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 29215 | 4 |
| B | 0 | 30809 | 3 |
| C | 0 | 32170 | 3 |
| D | 0 | 29831 | 6 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 21 | 0 |
| B | 0 | 21 | 0 |
| C | 0 | 21 | 0 |
| D | 0 | 21 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 14029 | 56 | 0.399173% |
| B | 14029 | 243 | 1.732126% |
| C | 14029 | 243 | 1.732126% |
| D | 14028 | 51 | 0.363559% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 16261 | 14033 | 7 | 7 | 0.04% | 0.05% |  |
| B | 16261 | 14033 | 93 | 93 | 0.57% | 0.66% |  |
| C | 16261 | 14033 | 224 | 224 | 1.38% | 1.60% |  |
| D | 16260 | 14032 | 24 | 24 | 0.15% | 0.17% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 128328 | 377.63 | 1647 | 1613 | 335.6 |
| A | 15 | 174 | 125994 | 370.68 | 1647 | 1613 | 335.6 |
| A | 15 | 236 | 81910 | 239.3 | 1647 | 1613 | 335.6 |
| B | 0 | 228 | 576883 | 1804.68 | 1654 | 1612 | 318.8 |
| B | 4 | 81 | 80684 | 248.06 | 1654 | 1612 | 318.8 |
| B | 14 | 167 | 56286 | 171.52 | 1654 | 1612 | 318.8 |
| C | 8 | 208 | 1053972 | 2837.83 | 1602 | 1609 | 370.8 |
| C | 9 | 16 | 233315 | 624.82 | 1602 | 1609 | 370.8 |
| C | 1 | 16 | 71710 | 189.04 | 1602 | 1609 | 370.8 |
| D | 2 | 152 | 264411 | 665.92 | 1609 | 1558 | 394.7 |
| D | 11 | 241 | 196169 | 493.03 | 1609 | 1558 | 394.7 |
| D | 2 | 14 | 61823 | 152.68 | 1609 | 1558 | 394.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
