| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A02_191T02_9000000852_06426cztM0_level2.evt | modeM0/AS1A02_191T02_9000000852_06426cztM0_level2_quad_clean.evt |
| Size (bytes) | 1,037,491,200 | 231,194,880 |
| Size | 989.4 MB | 220.5 MB |
| Events in quadrant A | 6,998,545 | 1,503,701 |
| Events in quadrant B | 7,264,771 | 1,569,272 |
| Events in quadrant C | 6,808,426 | 1,483,526 |
| Events in quadrant D | 9,310,843 | 1,388,077 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 314 | 0 |
| B | 0 | 314 | 0 |
| C | 0 | 314 | 0 |
| D | 0 | 314 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 31224 | 4 |
| B | 0 | 31652 | 3 |
| C | 0 | 31267 | 3 |
| D | 0 | 38695 | 3 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 38 | 0 |
| B | 0 | 38 | 0 |
| C | 0 | 38 | 0 |
| D | 0 | 38 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 15333 | 55 | 0.358703% |
| B | 15333 | 71 | 0.463054% |
| C | 15333 | 13 | 0.084784% |
| D | 15333 | 471 | 3.071806% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 19158 | 15336 | 0 | 0 | 0.00% | 0.00% |  |
| B | 19158 | 15336 | 1 | 1 | 0.01% | 0.01% |  |
| C | 19158 | 15336 | 0 | 0 | 0.00% | 0.00% |  |
| D | 19158 | 15336 | 396 | 396 | 2.07% | 2.58% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 236 | 19675 | 49.57 | 1805 | 1765 | 361.3 |
| A | 0 | 226 | 17325 | 43.06 | 1805 | 1765 | 361.3 |
| A | 12 | 194 | 17072 | 42.36 | 1805 | 1765 | 361.3 |
| B | 8 | 3 | 57510 | 163.74 | 1829 | 1792 | 340.3 |
| B | 4 | 81 | 44954 | 126.84 | 1829 | 1792 | 340.3 |
| B | 12 | 111 | 34447 | 95.96 | 1829 | 1792 | 340.3 |
| C | 1 | 16 | 34905 | 83.93 | 1732 | 1739 | 395.1 |
| C | 13 | 61 | 13786 | 30.49 | 1732 | 1739 | 395.1 |
| C | 9 | 54 | 13232 | 29.09 | 1732 | 1739 | 395.1 |
| D | 11 | 241 | 2100941 | 5069.16 | 1715 | 1663 | 414.1 |
| D | 2 | 152 | 279861 | 671.77 | 1715 | 1663 | 414.1 |
| D | 14 | 206 | 147712 | 352.67 | 1715 | 1663 | 414.1 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
