| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A02_191T01_9000000854_06442cztM0_level2.evt | modeM0/AS1A02_191T01_9000000854_06442cztM0_level2_quad_clean.evt |
| Size (bytes) | 383,359,680 | 78,684,480 |
| Size | 365.6 MB | 75.0 MB |
| Events in quadrant A | 2,699,480 | 499,960 |
| Events in quadrant B | 2,883,083 | 515,560 |
| Events in quadrant C | 2,581,074 | 489,895 |
| Events in quadrant D | 3,047,955 | 468,282 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 118 | 0 |
| B | 0 | 118 | 0 |
| C | 0 | 118 | 0 |
| D | 0 | 118 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12026 | 2 |
| B | 0 | 12334 | 1 |
| C | 0 | 11947 | 1 |
| D | 0 | 13095 | 1 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 12 | 0 |
| B | 0 | 12 | 0 |
| C | 0 | 12 | 0 |
| D | 0 | 12 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 5856 | 81 | 1.383197% |
| B | 5856 | 76 | 1.297814% |
| C | 5856 | 21 | 0.358607% |
| D | 5856 | 55 | 0.939208% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7001 | 5857 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7001 | 5857 | 6 | 6 | 0.09% | 0.10% |  |
| C | 7001 | 5857 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7001 | 5857 | 7 | 7 | 0.10% | 0.12% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 10695 | 70.8 | 693 | 677 | 141.5 |
| A | 10 | 133 | 10433 | 68.95 | 693 | 677 | 141.5 |
| A | 15 | 236 | 7585 | 48.82 | 693 | 677 | 141.5 |
| B | 11 | 51 | 58420 | 433.12 | 695 | 679 | 133.3 |
| B | 15 | 204 | 51403 | 380.49 | 695 | 679 | 133.3 |
| B | 4 | 80 | 27108 | 198.25 | 695 | 679 | 133.3 |
| C | 13 | 61 | 5379 | 30.86 | 661 | 664 | 152.8 |
| C | 8 | 222 | 1862 | 7.84 | 661 | 664 | 152.8 |
| C | 3 | 202 | 1628 | 6.31 | 661 | 664 | 152.8 |
| D | 2 | 152 | 367735 | 2270.56 | 664 | 641 | 161.7 |
| D | 2 | 63 | 50360 | 307.52 | 664 | 641 | 161.7 |
| D | 2 | 136 | 36443 | 221.44 | 664 | 641 | 161.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
