| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G06_139T02_9000000862_06468cztM0_level2.evt | modeM0/AS1G06_139T02_9000000862_06468cztM0_level2_quad_clean.evt |
| Size (bytes) | 459,840,960 | 74,701,440 |
| Size | 438.5 MB | 71.2 MB |
| Events in quadrant A | 3,746,689 | 454,949 |
| Events in quadrant B | 3,274,660 | 468,694 |
| Events in quadrant C | 3,271,955 | 451,729 |
| Events in quadrant D | 3,189,624 | 431,283 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 13 | 0 |
| B | 0 | 13 | 0 |
| C | 0 | 13 | 0 |
| D | 0 | 13 | 0 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15292 | 3 |
| B | 0 | 13763 | 2 |
| C | 0 | 13921 | 2 |
| D | 0 | 13737 | 2 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 134 | 0 |
| B | 0 | 134 | 0 |
| C | 0 | 134 | 0 |
| D | 0 | 134 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6523 | 42 | 0.643876% |
| B | 6523 | 28 | 0.429250% |
| C | 6523 | 31 | 0.475241% |
| D | 6524 | 15 | 0.229920% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7833 | 6524 | 0 | 0 | 0.00% | 0.00% |  |
| B | 7833 | 6524 | 7 | 7 | 0.09% | 0.11% |  |
| C | 7833 | 6524 | 38 | 38 | 0.49% | 0.58% |  |
| D | 7834 | 6525 | 1 | 1 | 0.01% | 0.02% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 236 | 637749 | 3915.72 | 802 | 785 | 162.7 |
| A | 8 | 15 | 15293 | 89.19 | 802 | 785 | 162.7 |
| A | 0 | 226 | 7692 | 42.46 | 802 | 785 | 162.7 |
| B | 15 | 35 | 28346 | 179.18 | 817 | 799 | 153.7 |
| B | 0 | 229 | 26064 | 164.33 | 817 | 799 | 153.7 |
| B | 12 | 111 | 15647 | 96.58 | 817 | 799 | 153.7 |
| C | 1 | 16 | 203791 | 1123.2 | 782 | 787 | 180.7 |
| C | 12 | 4 | 8827 | 44.48 | 782 | 787 | 180.7 |
| C | 10 | 170 | 6997 | 34.36 | 782 | 787 | 180.7 |
| D | 8 | 195 | 90617 | 474.06 | 778 | 757 | 189.6 |
| D | 2 | 152 | 59457 | 309.67 | 778 | 757 | 189.6 |
| D | 2 | 136 | 34109 | 175.95 | 778 | 757 | 189.6 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
