| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1A02_046T01_9000000864_06487cztM0_level2.evt | modeM0/AS1A02_046T01_9000000864_06487cztM0_level2_quad_clean.evt |
| Size (bytes) | 283,397,760 | 78,534,720 |
| Size | 270.3 MB | 74.9 MB |
| Events in quadrant A | 1,987,591 | 528,594 |
| Events in quadrant B | 2,193,392 | 528,965 |
| Events in quadrant C | 1,837,546 | 513,877 |
| Events in quadrant D | 2,260,577 | 494,293 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 9133 | 1 |
| B | 0 | 9607 | 1 |
| C | 0 | 8949 | 1 |
| D | 0 | 9659 | 1 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 88 | 0 |
| B | 0 | 88 | 0 |
| C | 0 | 88 | 0 |
| D | 0 | 88 | 0 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 1 | 251318637792 | 0 |
| B | 1 | -1 | -1 |
| C | 1 | -1 | -1 |
| D | 1 | -1 | -1 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 4447 | 26 | 0.584664% |
| B | 4447 | 54 | 1.214302% |
| C | 4447 | 5 | 0.112435% |
| D | 4447 | 43 | 0.966944% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 4447 | 4447 | 3 | 3 | 0.07% | 0.07% |  |
| B | 4447 | 4447 | 25 | 25 | 0.56% | 0.56% |  |
| C | 4447 | 4447 | 0 | 0 | 0.00% | 0.00% |  |
| D | 4447 | 4447 | 26 | 26 | 0.58% | 0.58% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 8 | 15 | 60036 | 589.66 | 492 | 482 | 101.0 |
| A | 15 | 234 | 11981 | 113.86 | 492 | 482 | 101.0 |
| A | 15 | 236 | 9352 | 87.82 | 492 | 482 | 101.0 |
| B | 0 | 228 | 85560 | 902.33 | 491 | 479 | 94.3 |
| B | 0 | 219 | 66179 | 696.78 | 491 | 479 | 94.3 |
| B | 0 | 214 | 54974 | 577.95 | 491 | 479 | 94.3 |
| C | 13 | 61 | 3886 | 31.54 | 469 | 470 | 108.3 |
| C | 12 | 4 | 2279 | 16.7 | 469 | 470 | 108.3 |
| C | 1 | 16 | 1605 | 10.48 | 469 | 470 | 108.3 |
| D | 8 | 195 | 242348 | 2108.07 | 471 | 456 | 114.7 |
| D | 2 | 152 | 81147 | 703.22 | 471 | 456 | 114.7 |
| D | 2 | 33 | 64578 | 558.82 | 471 | 456 | 114.7 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
