| Param | Original file | Final file |
|---|---|---|
| Filename | modeM0/AS1G06_134T11_9000000870_06497cztM0_level2.evt | modeM0/AS1G06_134T11_9000000870_06497cztM0_level2_quad_clean.evt |
| Size (bytes) | 462,916,800 | 110,851,200 |
| Size | 441.5 MB | 105.7 MB |
| Events in quadrant A | 3,276,961 | 722,530 |
| Events in quadrant B | 3,172,638 | 753,304 |
| Events in quadrant C | 2,908,258 | 739,528 |
| Events in quadrant D | 4,218,511 | 687,324 |
| Mode M0 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 14367 | 3 |
| B | 0 | 13873 | 2 |
| C | 0 | 13378 | 2 |
| D | 0 | 16821 | 2 |
| Mode M9 | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 15 | 0 |
| B | 0 | 15 | 0 |
| C | 0 | 15 | 0 |
| D | 0 | 16 | 0 |
| Mode SS | |||
|---|---|---|---|
| Quadrant | BADHDUFLAG | Total packets | Discarded packets |
| A | 0 | 132 | 0 |
| B | 0 | 132 | 0 |
| C | 0 | 132 | 0 |
| D | 0 | 132 | 0 |
| Quadrant | Total seconds | Saturated seconds | Saturation percentage |
|---|---|---|---|
| A | 6520 | 256 | 3.926380% |
| B | 6520 | 58 | 0.889571% |
| C | 6520 | 12 | 0.184049% |
| D | 6520 | 193 | 2.960123% |
Noise dominated data is calculated using 1-second bins in cleaned event files. If a bin has >2000 counts, and if more than 50% of those come from <1% of pixels, then it is considered to be noise-dominated and hence unusable.
| Quadrant | # 1 sec bins | Bins with >0 counts | Bins with >2000 counts | High rate bins dominated by noise | Noise dominated (total time) | Noise dominated (detector-on time) | Marked lightcurve |
|---|---|---|---|---|---|---|---|
| A | 7770 | 6521 | 17 | 17 | 0.22% | 0.26% |  |
| B | 7770 | 6521 | 13 | 13 | 0.17% | 0.20% |  |
| C | 7770 | 6521 | 0 | 0 | 0.00% | 0.00% |  |
| D | 7770 | 6521 | 112 | 112 | 1.44% | 1.72% |  |
Top three noisy pixels from each quadrant. If the there are fewer than three noisy pixels in the level2.evt file, extra rows are filled as -1
| Pixel properties | Quadrant properties | ||||||
|---|---|---|---|---|---|---|---|
| Quadrant | DetID | PixID | Counts | Sigma | Mean | Median | Sigma |
| A | 15 | 236 | 300582 | 1995.55 | 748 | 733 | 150.3 |
| A | 8 | 15 | 77502 | 510.91 | 748 | 733 | 150.3 |
| A | 15 | 174 | 19688 | 126.15 | 748 | 733 | 150.3 |
| B | 15 | 35 | 37320 | 254.31 | 773 | 757 | 143.8 |
| B | 0 | 219 | 34917 | 237.6 | 773 | 757 | 143.8 |
| B | 4 | 81 | 27014 | 182.63 | 773 | 757 | 143.8 |
| C | 1 | 16 | 13084 | 72.81 | 741 | 744 | 169.5 |
| C | 13 | 61 | 6102 | 31.62 | 741 | 744 | 169.5 |
| C | 7 | 247 | 2270 | 9.0 | 741 | 744 | 169.5 |
| D | 8 | 195 | 566901 | 3268.2 | 716 | 693 | 173.2 |
| D | 2 | 152 | 311162 | 1792.06 | 716 | 693 | 173.2 |
| D | 10 | 15 | 166571 | 957.46 | 716 | 693 | 173.2 |
Histogram calculated using DETX and DETY for each event in the final _common_clean file
| Quadrant A |  |
 |
Quadrant B |
|---|---|---|---|
| Quadrant D |  |
 |
Quadrant C |
| Plot type | Count rate plots | Images |
|---|---|---|
| Comparison with Poisson distribution Blue bars denote a histogram of data divided into 1 sec bins. Red curve is a Poisson curve with rate = median count rate of data. |
 |
 |
| Quadrant-wise count rates Data is divided into 100 sec bins |
 |
|
| Module-wise count rates for Quadrant A Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant B Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant C Data is divided into 100 sec bins |
 |
 |
| Module-wise count rates for Quadrant D Data is divided into 100 sec bins |
 |
 |
| Parameter | Plot |
|---|---|
| CZT HV Monitor |  |
| D_VDD |  |
| Temperature 1 |  |
| Veto HV Monitor |  |
| Veto LLD |  |
| Alpha Counter |  |
| _CPM_Rate |  |
| CZT Counter |  |
| +2.5 Volts monitor |  |
| +5 Volts monitor |  |
| _ROLL_ROT |  |
| _Roll_DEC |  |
| _Roll_RA |  |
| Veto Counter |  |
